White square ceiling-mounted wireless access point with smooth rounded edges and a single status LED, shown from below

HPE Networking Instant On

HPE Networking Instant On R4W01A AP22 access point

SKU CH-ZM1S-K5NNM MPN R4W01A

Indoor Wi-Fi 6 access point with dual 2x2 radios, PoE-powered, certified for medical environments

  • WiFi GenerationWi-Fi 6
  • Wireless Data RatesUp to 500 Mbps
  • Frequency BandDual Radio for simultaneous dual-band operation 5 GHz 802.11
  • WAN Ports1 x RJ-45
  • InterfaceEthernet Port
  • StandardsIEEE 802.11ax

WiFi Technology Wi-Fi 6

Struck-through versions exist but are not stocked here.

Model AP22

Power Source Not Included

  • Wi-Fi 6 dual-band delivers up to 1.2 Gbps on 5 GHz
  • 4 GHz radio reaches 574 Mbps for legacy device support
  • PoE 802.3af powers the AP through the single uplink cable
  • Medical-grade EN 60601 certification allows safe use in healthcare areas
  • Compact 1.5 × 6.3 × 6.3 in design weighs only 1.1 lb

Indoor Wi-Fi 6 access point for small businesses

The HPE Networking Instant On AP22 is a dual-band indoor wireless access point built for small offices, retail spaces and clinics that need reliable Wi-Fi 6 coverage without a dedicated controller. It operates on 2.4 GHz and 5 GHz simultaneously with 2x2 MIMO, delivering up to 1.2 Gbps on 5 GHz and 574 Mbps on 2.4 GHz. Management is handled through a simple web GUI and templates so the unit can be online in minutes.

PoE-powered deployment with medical-grade compliance

The AP22 draws power from a single Gigabit Ethernet uplink that supports 802.3af PoE, eliminating the need for a separate DC adapter when a compatible switch is available. Integrated down-tilt omni-directional antennas provide 4.3 dBi gain at 2.4 GHz and 5.6 dBi at 5 GHz for consistent coverage. The hardware meets EN 60601-1-1 and EN 60601-1-2 standards, allowing installation in healthcare environments where electromagnetic compatibility is required.

Capacity for typical small-office loads

With a maximum wireless data rate of 500 Mbps and support for OFDMA plus bi-directional MU-MIMO, the access point comfortably serves dozens of concurrent laptops, phones and IoT devices in meeting rooms, open-plan areas or patient waiting zones. Target Wake Time scheduling helps preserve battery life on connected clients. Environments that demand higher aggregate throughput, multi-gigabit uplinks or outdoor-rated enclosures will need a different model.

Highlights

  • Wi-Fi 6 dual-band delivers up to 1.2 Gbps on 5 GHz
  • 4 GHz radio reaches 574 Mbps for legacy device support
  • PoE 802.3af powers the AP through the single uplink cable
  • Medical-grade EN 60601 certification allows safe use in healthcare areas
  • Compact 1.5 × 6.3 × 6.3 in design weighs only 1.1 lb

Specifications

WiFi GenerationWi-Fi 6
Wireless Data RatesUp to 500 Mbps
Frequency BandDual Radio for simultaneous dual-band operation
5 GHz 802.11ax 2x2 MIMO for up to 1.2 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)
WAN Ports1 x RJ-45
InterfaceEthernet Port
StandardsIEEE 802.11ax
AntennaIntegrated down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 4.3dBi in 2.4GHz and 5.6dBi in 5GHz (of the effective, combined pattern for both antennas in each band).
LAN Ports(1) uplink Gigabit Ethernet port, with POE-in support (802.3af)
Power SupplyPower over Ethernet (POE): 802.3af (class 3)
DC power (12V)
Note: Power sources are sold separately
BrandHPE Networking Instant On
SeriesHPE Networking Instant On Access Points
ModelR4W01A
Part NumberR4W01A
Dimensions1.5 x 6.3 x 6.3 in
Weight1.1 lb
FeaturesEN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3
Shipping weight0.91 kg
Package size305 × 254 × 203 mm
