White square ceiling-mounted Wi-Fi 6 access point with status LEDs and Kensington slot

HPE Networking Instant On

HPE Networking Instant On R9B27A access point

SKU CH-JGHX-J4DD7 MPN R9B27A

Dual-band Wi-Fi 6 access point with 4×4 5 GHz radio, 2.5 GbE uplink and Bluetooth for mesh backhaul

  • StandardsUltra-fast 802.11ax, 4x4:4
  • Frequency BandDual radio for simultaneous dual-band operation 5 GHz 802.11
  • AntennaDown-tilt omni-directional antennas for 2x2 MIMO with peak a
  • LAN PortsUplink 2.5 Gigabit Ethernet port, with PoE-in support (802.3
  • Power SupplyPower over Ethernet (POE): 802.3at (class 4) Max power consu
  • Dimensions2 x 8 x 8 in

WiFi Technology Wi-Fi 6

Struck-through versions exist but are not stocked here.

Model AP25

Power Source Not Included

  • Ultra-fast Wi-Fi 6 with 4x4 MU-MIMO delivers up to 4.8 Gbps on 5 GHz
  • 5 Gigabit Ethernet uplink removes wired bottlenecks for high-throughput clients
  • 160 MHz channel support doubles bandwidth per connection
  • Smart mesh backhaul at 160 MHz extends coverage without cables
  • Medical-grade EN 60601 certified for safe deployment in healthcare areas

HPE Instant On AP25 Wi-Fi 6 access point

The HPE Networking Instant On R9B27A is a dual-band Wi-Fi 6 indoor access point built for small offices, clinics and retail spaces that need high-density coverage. It delivers 4x4 MIMO on the 5 GHz radio for up to 4.8 Gbps and 2x2 MIMO on the 2.4 GHz radio for up to 574 Mbps. A 2.5 Gigabit Ethernet uplink with PoE-in support connects the unit to the wired network.

Ceiling or wall mounting with PoE or DC power

The AP includes a mounting bracket for ceiling or wall installation and a Kensington security slot for physical locking. Power comes from an 802.3at PoE switch or injector (up to 20.1 W) or a separate 12 V DC adapter (15.9 W); neither is included unless a bundle SKU is purchased. A reset button and LED status indicators simplify initial setup and troubleshooting.

Verify PoE budget, regulatory domain

Ensure your PoE switch or injector provides 802.3at class 4 power and that the 2.5 GbE uplink matches your switch ports. This is the US regulatory domain model; it cannot be used in regions requiring a different country code. Confirm the ceiling or wall material can support the 2.6 lb unit and that the down-tilt antenna pattern suits the room layout.

Highlights

  • Ultra-fast Wi-Fi 6 with 4x4 MU-MIMO delivers up to 4.8 Gbps on 5 GHz
  • 5 Gigabit Ethernet uplink removes wired bottlenecks for high-throughput clients
  • 160 MHz channel support doubles bandwidth per connection
  • Smart mesh backhaul at 160 MHz extends coverage without cables
  • Medical-grade EN 60601 certified for safe deployment in healthcare areas

Specifications

BrandHPE Networking Instant On
SeriesHPE Networking Instant On Access Points
ModelR9B27A
StandardsUltra-fast 802.11ax, 4x4:4
Frequency BandDual radio for simultaneous dual-band operation
5 GHz 802.11ax 4x4 MIMO for up to 4.8 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)
AntennaDown-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 3.77 dBi in 2.4GHz and 4x4 MIMO with peak antenna gain of 4.55 dBi in 5GHz (of the effective, combined pattern for both antennas in each band)
LAN PortsUplink 2.5 Gigabit Ethernet port, with PoE-in support (802.3at)
DC power connector (12V) Bluetooth
Low Energy (BLE) radio LED status indicators
Reset/LED control button
Kensington security slot
Power SupplyPower over Ethernet (POE): 802.3at (class 4)
Max power consumption (worst-case): 20.1W (PoE), 15.9W (DC) DC power (12V)
Note: Power sources are sold separately unless you purchase the bundle SKU
Dimensions2 x 8 x 8 in
Weight2.6 lb
FeaturesEN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3
Shipping weight1.36 kg
Package size218 × 216 × 69 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I verify the AP25 is delivering the 4.8 Gbps 5 GHz rate after installation?

Check the Instant On dashboard for client link speeds showing 160 MHz channel width and 4x4 MIMO on the 5 GHz radio; the LED status indicators will display solid green when the 2.5 Gigabit Ethernet uplink is active and PoE-in is supplying up to 20.1 W.

What ships with the R9B27A and which power source must be purchased separately?

The box contains the AP25 unit with down-tilt omni-directional antennas, a Kensington security slot, reset/LED control button and Bluetooth Low Energy radio; power sources are sold separately unless you buy the bundle SKU, so you need an 802.3at PoE injector or a 12 V DC adapter.

Which capacity fits a clinic needing EN 60601-1-1 compliance and 574 Mbps on 2.4 GHz?

The single R9B27A model meets EN 60601-1-1 and EN 60601-1-2 for medical environments and provides 2.4 GHz 802.11ax 2x2 MIMO up to 574 Mbps alongside the 5 GHz 4x4 radio, so no higher-capacity version is required.
