White square ceiling-mounted wireless access point with smooth matte finish and subtle brand badge

HPE Networking Instant On

HPE Networking Instant On R2X05A access point

SKU CH-Q2KF-P2PSX MPN R2X05A

Dual-band indoor access point with 4x4 MU-MIMO on 5 GHz, PoE-powered, plenum-rated and certified for medical environments

  • StandardsIEEE 802.11ac, 802.11n
  • Frequency BandDual Radio for simultaneous dual-band operation 5 GHz 802.11
  • AntennaIntegrated downtilt omni-directional antennas with maximum i
  • LAN Ports(1) uplink Gigabit Ethernet port, with POE-in support (802.3
  • Power SupplyPower over Ethernet (POE): 802.3af (class 3) DC power (12V)
  • Dimensions1.6 x 7.2 x 7.2 in

WiFi Technology Wi-Fi 5

Struck-through versions exist but are not stocked here.

Model AP15

Power Source Not Included

  • Dual-band Wi-Fi 5 delivers up to 1,733 Mbps on 5 GHz and 300 Mbps on 2.4 GHz
  • PoE 802.3af powers the unit through the single Gigabit uplink port
  • UL 2043 plenum rating and EN 60601 compliance allow deployment in ceilings and medical areas
  • Smart Mesh clustering pushes config changes instantly and fails over automatically for continuous coverage
  • Compact 1.6 x 7.2 x 7.2 in design weighs 1.5 lb for discreet indoor mounting

Indoor Wi-Fi 5 access point for small to medium

The HPE Networking Instant On AP15 (R2X05A) is a dual-radio indoor wireless access point built for small and medium environments. It delivers simultaneous 2.4 GHz and 5 GHz operation with combined data rates up to 2 Gbps. The unit supports 802.11ac Wave 2 with 4x4 MU-MIMO on the 5 GHz band and 2x2 MIMO on the 2.4 GHz band. It is suited for offices, clinics or retail sites needing reliable coverage for video, voice and conferencing.

PoE-powered unit with single Gigabit uplink

The access point draws power through its single Gigabit Ethernet port using 802.3af PoE (class 3) or an optional 12 V DC supply, neither of which is included in the box. This single-cable approach frees the installer from running separate mains wiring to the mounting location. A web-based GUI and configuration templates allow the device to be provisioned in minutes, while clustering automatically replicates settings across multiple units and promotes a secondary AP if the primary fails.

Plenum-rated enclosure with medical certifications

The chassis carries a UL 2043 plenum rating and meets EN 60601-1-1 and EN 60601-1-2 for deployment in healthcare settings. Integrated downtilt omni-directional antennas provide 3.6 dBi gain at 2.4 GHz and 6.0 dBi at 5 GHz. With no moving parts, the unit operates silently. Typical power draw stays within the 802.3af class 3 budget, so thermal output is minimal in normal use.

Highlights

  • Dual-band Wi-Fi 5 delivers up to 1,733 Mbps on 5 GHz and 300 Mbps on 2.4 GHz
  • PoE 802.3af powers the unit through the single Gigabit uplink port
  • UL 2043 plenum rating and EN 60601 compliance allow deployment in ceilings and medical areas
  • Smart Mesh clustering pushes config changes instantly and fails over automatically for continuous coverage
  • Compact 1.6 x 7.2 x 7.2 in design weighs 1.5 lb for discreet indoor mounting

Specifications

BrandHPE Networking Instant On
SeriesHPE Networking Instant On Access Points
ModelR2X05A
StandardsIEEE 802.11ac, 802.11n
Frequency BandDual Radio for simultaneous dual-band operation
5 GHz 802.11ac 4x4 MIMO for up to 1,733 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5)
2.4 GHz 802.11n 2x2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4)
AntennaIntegrated downtilt omni-directional antennas with maximum individual antenna gain of 3.6dBi in 2.4GHz and 6.0dBi in 5GHz.
LAN Ports(1) uplink Gigabit Ethernet port, with POE-in support (802.3af)
Power SupplyPower over Ethernet (POE): 802.3af (class 3)
DC power (12V)
Note: Power sources are sold separately
Dimensions1.6 x 7.2 x 7.2 in
Weight1.5 lb
FeaturesUL 2043 plenum rating
EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3, Enhanced Open (OWE)
Shipping weight1.07 kg
Package size216 × 203 × 89 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What is the maximum wireless data rate on the 5 GHz radio?

The 5 GHz radio supports up to 1733 Mbps using 4x4 MIMO with Multi-User MIMO capability.

How much power does the AP draw over its PoE uplink?

It operates on 802.3af Class 3 PoE, which supplies up to 15 W at the port.

Does the box include a 12 V DC power adapter?

No, the power adapter is sold separately; the unit can be powered via PoE or an optional 12 V DC source.
