White square ceiling-mount access point, flat profile, subtle LED indicator

HPE Networking Instant On

HPE Networking Instant On AP11 R2W95A access point

SKU CH-MW4B-FXNQE MPN R2W95A

Dual-band Wi-Fi 5 access point with PoE support and integrated antennas for small-business indoor coverage

  • StandardsIEEE 802.11ac, 802.11n
  • Frequency BandDual radio for simultaneous dual-band operation. 5 GHz 802.1
  • AntennaIntegrated down-tilt omni-directional antennas with maximum
  • LAN Ports(1) uplink Gigabit Ethernet port, with POE-in support (802.3
  • Power SupplyPower over Ethernet (POE): 802.3af (class 3) or DC power (12
  • Dimensions1.3 x 6.0 x 6.0 in

WiFi Technology Wi-Fi 5

Struck-through versions exist but are not stocked here.

Model AP11

Power Source Not Included

  • Dual-band Wi-Fi 5 reaches 867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz
  • Gigabit Ethernet uplink with 802.3af PoE-in powers the AP without a separate adapter
  • Integrated down-tilt omni antennas provide 3.3 dBi gain at 2.4 GHz and 5.8 dBi at 5 GHz
  • UL 2043 plenum rating plus EN 60601 medical certifications allow deployment in ceilings and healthcare areas
  • Managed through the Aruba Instant On Cloud app for quick setup and two-factor authentication security

Indoor Wave 2 access point

The HPE Networking Instant On AP11 R2W95A is a dual-radio indoor access point built for low- to medium-density small business environments. It delivers simultaneous 2.4 GHz and 5 GHz operation with Wave 2 802.11ac performance. The unit is managed through the Aruba Instant On Cloud app for quick setup and ongoing control. It ships without a power adapter and requires PoE or a separate 12 V supply.

Suited for simple deployments, not high density

This access point fits small offices, retail shops, dental offices, home networks and similar spaces where device counts stay modest. It supports WPA2, WPA3 and Enhanced Open for modern security needs. Buyers who need higher client capacity, dedicated IoT radios or outdoor-rated hardware should look at other models. The single Gigabit uplink also limits aggregate throughput in busy scenarios.

PoE-powered, no adapter included

Power is supplied through the 802.3af Class 3 PoE uplink port or an optional 12 V DC source; neither is provided in the box. Verify that your switch or injector can deliver the required class before purchase. The plenum-rated chassis meets UL 2043 and medical-environment standards for ceiling installations. Integrated antennas provide 3.3 dBi gain at 2.4 GHz and 5.8 dBi at 5 GHz.

Highlights

  • Dual-band Wi-Fi 5 reaches 867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz
  • Gigabit Ethernet uplink with 802.3af PoE-in powers the AP without a separate adapter
  • Integrated down-tilt omni antennas provide 3.3 dBi gain at 2.4 GHz and 5.8 dBi at 5 GHz
  • UL 2043 plenum rating plus EN 60601 medical certifications allow deployment in ceilings and healthcare areas
  • Managed through the Aruba Instant On Cloud app for quick setup and two-factor authentication security

Specifications

BrandHPE Networking Instant On
SeriesHPE Networking Instant On Access Points
ModelR2W95A
StandardsIEEE 802.11ac, 802.11n
Frequency BandDual radio for simultaneous dual-band operation.
5 GHz 802.11ac 2x2 MIMO for up to 867 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5).
2.4 GHz 802.11n 2x2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4).
AntennaIntegrated down-tilt omni-directional antennas with maximum individual antenna gain of 3.3dBi in 2.4GHz and 5.8dBi in 5GHz
LAN Ports(1) uplink Gigabit Ethernet port, with POE-in support (802.3af)
Power SupplyPower over Ethernet (POE): 802.3af (class 3) or DC power (12V). Power sources sold separately.
Dimensions1.3 x 6.0 x 6.0 in
Weight0.4 lb
FeaturesUL 2043 plenum rating
EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3, Enhanced Open (OWE)
Shipping weight5.44 kg
Package size191 × 178 × 64 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the R2W95A come with a PoE injector or a 12 V power adapter?

Neither is included; the AP requires an 802.3af Class 3 PoE switch or a separate 12 V DC supply.

Will my existing 802.11n laptops and phones connect to the AP11?

Yes — the dual radio supports 802.11n on 2.4 GHz and 802.11ac on 5 GHz, so legacy clients join at up to 300 Mbps.

How can I confirm the AP11 is operating correctly after mounting it?

Open the Aruba Instant On mobile app; it shows the AP online, displays connected clients, and reports the 2.4 GHz and 5 GHz radios active.
