White square ceiling-mounted wireless access point with smooth matte finish and recessed LED indicator

HPE Networking Instant On

HPE Networking Instant On R2X00A access point

SKU CH-Z67C-PYDE5 MPN R2X00A

Dual-band indoor access point with 802.11ac Wave 2, PoE-powered, plenum-rated for medical spaces

  • StandardsIEEE 802.11ac, 802.11n
  • Frequency BandDual Radio for simultaneous dual-band operation 5 GHz 802.11
  • AntennaIntegrated downtilt omni-directional antennas with maximum i
  • LAN Ports(1) uplink Gigabit Ethernet port, with POE-in support (802.3
  • Power SupplyPower over Ethernet (POE): 802.3af (class 3) DC power (12V)
  • Dimensions1.3 x 6.2 x 6.2 in

WiFi Technology Wi-Fi 5

Struck-through versions exist but are not stocked here.

Model AP12

Power Source Not Included

  • Simultaneous dual-band operation supports 1.6 Gbps combined throughput
  • PoE 802.3af power removes the need for a separate adapter
  • UL 2043 plenum rating allows installation in air-handling spaces
  • Medical-grade EN 60601 compliance suits healthcare environments
  • Automatic cluster failover keeps Wi-Fi online during primary AP outage

Small-business wireless access point

The HPE Networking Instant On R2X00A is an indoor Wi-Fi 5 access point built for small organisations that need reliable connectivity without a dedicated IT team. It ships without a power adapter and draws power through its single Gigabit Ethernet uplink using 802.3af PoE or an optional 12 V DC source.

Dual-radio 802.11ac Wave 2 with 3x3 MIMO

The decisive specification is the 5 GHz radio, which runs 802.11ac Wave 2 3x3 MIMO at up to 80 MHz channel width for a 1,300 Mbps data rate, while the 2.4 GHz radio provides 2x2 MIMO at 300 Mbps. Together they deliver a combined throughput of 1.6 Gbps for video, voice and conferencing workloads.

Passive cooling with plenum-rated enclosure

The unit has no fan and relies on its compact 1.3 x 6.2 x 6.2 in housing to dissipate the modest heat from its PoE class 3 power budget. Integrated downtilt omni-directional antennas provide 3.9 dBi gain at 2.4 GHz and 5.4 dBi at 5 GHz. UL 2043 plenum rating and EN 60601 compliance allow installation in ceiling spaces and medical environments.

Highlights

  • Simultaneous dual-band operation supports 1.6 Gbps combined throughput
  • PoE 802.3af power removes the need for a separate adapter
  • UL 2043 plenum rating allows installation in air-handling spaces
  • Medical-grade EN 60601 compliance suits healthcare environments
  • Automatic cluster failover keeps Wi-Fi online during primary AP outage

Specifications

BrandHPE Networking Instant On
SeriesHPE Networking Instant On Access Points
ModelR2X00A
StandardsIEEE 802.11ac, 802.11n
Frequency BandDual Radio for simultaneous dual-band operation
5 GHz 802.11ac 3x3 MIMO for up to 1,300 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5)
2.4 GHz 802.11n 2x2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4)
AntennaIntegrated downtilt omni-directional antennas with maximum individual antenna gain of 3.9dBi in 2.4GHz and 5.4dBi in 5GHz
LAN Ports(1) uplink Gigabit Ethernet port, with POE-in support (802.3af)
Power SupplyPower over Ethernet (POE): 802.3af (class 3)
DC power (12V)
Note: Power sources are sold separately
Dimensions1.3 x 6.2 x 6.2 in
Weight1.1 lb
FeaturesUL 2043 plenum rating
EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3, Enhanced Open (OWE)
Shipping weight0.82 kg
Package size206 × 193 × 43 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the combined 1.6 Gbps figure mean for real devices connected to the R2X00A?

The 1.6 Gbps is the sum of the 5 GHz radio at up to 1300 Mbps and the 2.4 GHz radio at up to 300 Mbps; individual client speeds depend on device capabilities, distance and interference.

How does the 802.3af PoE class 3 input limit what the access point can draw?

The AP draws up to the class 3 limit from a standard PoE switch or injector, powering both radios and the Gigabit uplink without needing a separate 12 V adapter.

What mounting options suit the 6.2 by 6.2 inch footprint and plenum rating?

The 1.3 inch low profile and UL 2043 rating allow flush ceiling or wall mounting in air-handling spaces using the supplied bracket.
