White square ceiling-mount access point with four status LEDs and Kensington slot

HPE Networking Instant On

HPE Networking Instant On R9B32A access point

SKU CH-ZMHD-JD63S MPN R9B32A

Wi-Fi 6 dual-band access point with a 2.5 Gigabit Ethernet uplink, 4.8 Gbps 5 GHz throughput and medical-grade EN 60601 certification

  • StandardsUltra-fast 802.11ax, 4x4:4
  • Frequency BandDual radio for simultaneous dual-band operation 5 GHz 802.11
  • AntennaDown-tilt omni-directional antennas for 2x2 MIMO with peak a
  • LAN PortsUplink 2.5 Gigabit Ethernet port, with PoE-in support (802.3
  • Power SupplyPower over Ethernet (POE): 802.3at (class 4) Max power consu
  • Dimensions2 x 8 x 8 in

WiFi Technology Wi-Fi 6

Struck-through versions exist but are not stocked here.

Model AP25

Power Source Included

  • Wi-Fi 6 delivers up to 4.8 Gbps on 5 GHz for fast throughput
  • 5 GbE uplink with PoE-in simplifies cabling and powers the unit
  • 160 MHz channel width on both bands increases capacity for dense environments
  • Bluetooth Low Energy radio enables location services and easy onboarding
  • Medical-grade certifications EN 60601-1-1 and EN 60601-1-2 allow healthcare deployment

Wireless AP25 access point for small business

The HPE Networking Instant On R9B32A is a Wi-Fi 6 access point built for small offices and retail spaces that need high-density client support. It delivers 802.11ax performance with 4x4:4 spatial streams on the 5 GHz band and 2x2 MIMO on 2.4 GHz. The bundle includes a power supply unit for US deployments. Integrated Bluetooth Low Energy radio enables location-based services and simplified onboarding.

Thermals noise and power draw in normal use

The unit operates without fans, relying on passive cooling for silent operation in noise-sensitive areas. Maximum power consumption reaches 20.1 W when powered via PoE+ 802.3at and 15.9 W on 12 V DC input. Down-tilt omni-directional antennas provide 3.77 dBi gain at 2.4 GHz and 4.55 dBi at 5 GHz. LED indicators show status while a dedicated button controls lighting and reset functions.

Build integration with 2.5 GbE uplink and mesh

A single 2.5 Gigabit Ethernet port handles uplink traffic and accepts PoE+ for flexible placement without a nearby outlet. The Kensington security slot allows physical locking in shared environments. Mesh backhaul operates at 160 MHz channel width for high-throughput node links. Medical-grade certifications EN 60601-1-1 and EN 60601-1-2 support deployment in healthcare settings. WPA3 encryption secures client connections.

Highlights

  • Wi-Fi 6 delivers up to 4.8 Gbps on 5 GHz for fast throughput
  • 5 GbE uplink with PoE-in simplifies cabling and powers the unit
  • 160 MHz channel width on both bands increases capacity for dense environments
  • Bluetooth Low Energy radio enables location services and easy onboarding
  • Medical-grade certifications EN 60601-1-1 and EN 60601-1-2 allow healthcare deployment

Specifications

BrandHPE Networking Instant On
SeriesHPE Networking Instant On Access Points
ModelR9B32A
StandardsUltra-fast 802.11ax, 4x4:4
Frequency BandDual radio for simultaneous dual-band operation
5 GHz 802.11ax 4x4 MIMO for up to 4.8 Gbps wireless data rate, with Multi User MIMO support (Wi-Fi 6)
2.4 GHz 802.11ax 2x2 MIMO for up to 574 Mbps wireless data rate (Wi-Fi 6)
AntennaDown-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 3.77 dBi in 2.4GHz and 4x4 MIMO with peak antenna gain of 4.55 dBi in 5GHz (of the effective, combined pattern for both antennas in each band)
LAN PortsUplink 2.5 Gigabit Ethernet port, with PoE-in support (802.3at)
DC power connector (12V) Bluetooth
Low Energy (BLE) radio LED status indicators
Reset/LED control button
Kensington security slot
Power SupplyPower over Ethernet (POE): 802.3at (class 4)
Max power consumption (worst-case): 20.1W (PoE), 15.9W (DC) DC power (12V)
Note: Power sources are sold separately unless you purchase the bundle SKU
Dimensions2 x 8 x 8 in
Weight2.6 lb
FeaturesEN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments)
Wi-Fi Alliance certified (WFA) 802.11ax with (Wi-Fi 6), WPA2, WPA3
Shipping weight1.29 kg
Package size254 × 241 × 76 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I power the R9B32A and what is the common mistake with the 2.5 Gigabit uplink?

Connect the 2.5 Gigabit Ethernet uplink to a PoE+ 802.3at source or use the 12V DC jack. The mistake is using a standard PoE 802.3af injector which cannot supply the 20.1W peak draw.

Which parts of the R9B32A will need replacement after extended deployment?

The internal down-tilt omni-directional antennas and radios are fixed for life. Only the external PoE+ injector or 12V DC adapter may wear out and need swapping.

What thermal or throughput limit appears first when the AP25 runs at full 4.8 Gbps 5 GHz load?

The 20.1W PoE+ power ceiling is reached before thermal throttling, capping sustained 4x4 MIMO throughput at the 160MHz channel width limit.
