Black rectangular RFID reader with textured ABS+PC finish, red and green LEDs, IP65 rated

ZKTECO

ZKTECO KR602E+ID RFID Card Smart Reader 125KHZ 13.56MHZ office equipment

SKU CH-6T0W-VB98C

Dual-frequency RFID reader reads 125 kHz and 13.56 MHz cards at up to 10 cm range with Wiegand 26/34-bit output and IP65-rated ABS+PC housing

Models: Select KR602E+ID

  • Dual-frequency 125 kHz and 13.56 MHz card compatibility
  • Fast card reading with high RF sensitivity
  • IP65-rated for outdoor and indoor durability
  • Wiegand 26/34-bit output for access control systems
  • Wide -20 °C to +65 °C operating temperature range

Dual-Frequency RFID Reader

The ZKTECO KR602E+ID reads both 125 kHz ID cards and 13.56 MHz M1 cards. It suits offices, campuses or small facilities that need a single reader for mixed credential types. Installers gain one device for access control, attendance logging or anti-theft points without buying separate units.

Wiegand Output and Compact Mounting

The unit delivers 26-bit or 34-bit Wiegand data and accepts 9 to 12 V DC at up to 70 mA. Two input ports let an external controller drive the red and green LEDs and the beeper. Its 116 by 75 by 17.3 mm ABS+PC housing fits standard wall boxes and carries an IP65 rating for indoor or sheltered outdoor use.

Stable Operation Across Temperature Range

The reader functions from minus 20 °C to plus 65 °C in humidity up to 90 % non-condensing. Low current draw and the advanced RF front-end maintain consistent read ranges of 5 to 10 cm during continuous daily traffic. The dual-colour LEDs and audible beeper give immediate feedback without host intervention.

Highlights

  • Dual-frequency 125 kHz and 13.56 MHz card compatibility
  • Fast card reading with high RF sensitivity
  • IP65-rated for outdoor and indoor durability
  • Wiegand 26/34-bit output for access control systems
  • Wide -20 °C to +65 °C operating temperature range

Specifications

No published specifications for this item yet.

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How close must a card be for the KR602E+ID to read it reliably?

The reader detects cards at a distance of up to 5 to 10 cm depending on card type and mounting surface.

What are the thermal and acoustic characteristics when the reader operates continuously?

The unit draws a maximum of 70 mA at 9 to 12 V DC, has no fan and is rated for -20 to +65 °C ambient temperature.

Which controller interface does the KR602E+ID require to function?

It communicates through a 26 or 34 bit Wiegand output and needs a compatible access controller with matching Wiegand input.
