Black rectangular RFID reader with textured ABS plastic finish and dual-colour LED indicator, 116 by 75 by 17.3 mm

ZKTECO

ZKTECO KR602M+IC RFID Smart Reader Office Equipment

SKU CH-6Z0E-MAS2W

A dual-frequency RFID reader for access control and attendance, reading 125 kHz and 13.56 MHz cards up to 10 cm with Wiegand 26/34 bit output and IP65 protection

Models: Select KR602M+IC

  • Reads ID and M1 cards up to 10 cm distance
  • DC 9-12 V supply draws only 70 mA max
  • Wiegand 26 or 34 bit output formats
  • IP65 rated for dust and water protection
  • Operates from -20 °C to +65 °C ambient

Dual-frequency RFID reader for access control

The ZKTECO KR602M+IC reads 125KHZ and 13.56MHZ cards at a range up to 10CM. It outputs 26/34 bit Wiegand data for access control, attendance, charging and anti-theft systems. The unit runs on DC 9-12V with a maximum current draw of 70mA.

Check power and wiring before ordering

Your supply must deliver DC 9-12V and handle the 70mA peak load. The reader needs two input ports for external LED and buzzer control and provides a Wiegand output. Confirm your controller accepts 26/34 bit Wiegand and that the operating temperature range of -20° to +65°C suits the installation site.

Fits surface-mount builds with IP65 protection

The ABS+PC housing measures 116*75*17.3MM and weighs 120G, so it mounts on a wall or door frame without a back-box. Dual-colour LEDs and an onboard beeper give local status feedback, freeing the controller from driving separate indicators. IP65 rating allows outdoor or wet-area use.

Highlights

  • Reads ID and M1 cards up to 10 cm distance
  • DC 9-12 V supply draws only 70 mA max
  • Wiegand 26 or 34 bit output formats
  • IP65 rated for dust and water protection
  • Operates from -20 °C to +65 °C ambient

Specifications

No published specifications for this item yet.

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the ZKTECO KR602M+IC reader come with mounting hardware or a power supply in the box?

The unit is supplied as the reader only; mounting screws and a DC 9-12V power source must be purchased separately.

The supplier title lists KR601, KR602 and KR602M+IC — which version should I choose for both 125KHZ and 13.56MHZ cards?

Select the KR602M+IC model; it reads both 125KHZ ID cards and 13.56MHZ M1 cards, while the other variants support only one frequency.

What does the 5-10CM read range mean when the reader is mounted on a metal door frame?

The 5-10CM range is measured in free air; metal surfaces can reduce it, so allow extra clearance or use a spacer when installing on a metal frame.
