White rectangular wall-mounted Wi-Fi 7 access point with smooth matte finish

Ubiquiti Networks

Ubiquiti Networks U7-Pro-XG-Wall Wi-Fi 7 access point

SKU CH-W66P-CHPPZ MPN U7-Pro-XG-Wall

Wall-mounted Wi-Fi 7 access point with 10 GbE uplink, 6 GHz support and 300-plus user capacity for high-density deployments

  • ColorWhite
  • # of Users300+
  • WiFi GenerationWi-Fi 7
  • Device ManagementEthernet
  • Wireless Data RatesMax. Data Rate 6 GHz: 5.8 Gbps (BW320) 5 GHz: 4.3 Gbps (BW24
  • AntennaAntenna Gain 6 GHz: 6 dBi 5 GHz: 6 dBi 2.4 GHz: 4 dBi

Options U7 Pro XG Wall

Show 1 more configurations
  • Supports over 300 users with high-density Wi-Fi 7 connectivity
  • 10 GbE RJ45 port provides multi-gigabit wired backhaul capacity
  • Tri-band operation reaches 5.8 Gbps on 6 GHz, 4.3 Gbps on 5 GHz, 688 Mbps on 2.4 GHz
  • Operates from -30 °C to 40 °C with 5–95 % non-condensing humidity
  • NDAA compliant with CE, FCC and IC certifications for regulated deployments

High-density Wi-Fi 7 access point

The U7-Pro-XG-Wall is a wall-mounted wireless access point built for environments with 300-plus concurrent users. It delivers Wi-Fi 7 (802.11be) performance across 6 GHz, 5 GHz and 2.4 GHz bands with a single 10 GbE RJ45 uplink.

Suited for multi-gigabit uplinks.

This unit targets installers who need a 10 GbE backbone and 6 GHz spectrum in a wall form factor. It is not for projects that require ceiling mounting, PoE++ power budgets above 22 W, or outdoor-rated enclosures.

Deciding spec: 10 GbE uplink

The single 10 GbE RJ45 port sets the wired ceiling for aggregate wireless throughput. If the site cabling tops out at 2.5 GbE, the radio capacity cannot be fully utilised; if 10 GbE is available, the AP can serve its rated 5.8 Gbps on 6 GHz and 4.3 Gbps on 5 GHz.

Highlights

  • Supports over 300 users with high-density Wi-Fi 7 connectivity
  • 10 GbE RJ45 port provides multi-gigabit wired backhaul capacity
  • Tri-band operation reaches 5.8 Gbps on 6 GHz, 4.3 Gbps on 5 GHz, 688 Mbps on 2.4 GHz
  • Operates from -30 °C to 40 °C with 5–95 % non-condensing humidity
  • NDAA compliant with CE, FCC and IC certifications for regulated deployments

Specifications

BrandUbiquiti Networks
ModelU7 Pro XG Wall
Part NumberU7-Pro-XG-Wall
ColorWhite
# of Users300+
WiFi GenerationWi-Fi 7
Device ManagementEthernet
Wireless Data RatesMax. Data Rate
6 GHz: 5.8 Gbps (BW320)
5 GHz: 4.3 Gbps (BW240)
2.4 GHz: 688 Mbps (BW40)
Supported Data Rates
802.11be (WiFi 7):
- 6 GHz: 7.3 Mbps to 5.8 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/320)
- 5 GHz: 7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
802.11ax (WiFi 6):
- 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
-
802.11ac (WiFi 5):
- 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11n:
- 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
AntennaAntenna Gain
6 GHz: 6 dBi
5 GHz: 6 dBi
2.4 GHz: 4 dBi
Operating Range140 m (1,500 ft)
Interface(1) 10 GbE RJ45 port
MIMO6 GHz: 2 x 2 (DL/UL MU-MIMO)
5 GHz: 2 x 2 (DL/UL MU-MIMO)
2.4 GHz: 2 x 2 (DL/UL MU-MIMO)
Power SupplyPower Method: PoE+
Supported Voltage Range: 42.5-57V DC
Max Power Consumption22W
CertificationsCE, FCC, IC
ComplianceNDAA Compliant
TemperatureAmbient Operating Temperature: -30 to 40° C (-22 to 104° F)
HumidityAmbient Operating Humidity: 5 to 95% noncondensing
Dimensions155 x 108 x 33.5 mm
(6.1 x 4.3 x 1.3'')
Weight505 g (1.1 lb)
FeaturesWireless Meshing
Band Steering
802.11v BSS Transition Management
802.11r Fast Roaming
802.11k Radio Resource Management (RRM)
Advanced Radio Management
Passpoint (Hotspot 2.0)
Captive Hotspot Portal:
- Custom Branding Landing Page
- Voucher Authentication
- Payment-Based Authentication
- External Portal Server Support
- Password Authentication
- Guest Network Isolation
- Private Pre-Shared Key (PPSK)
- WiFi Speed Limiting
- Client Device Isolation
- WiFi Schedules
- RADIUS over TLS (RadSec)
- Dynamic RADIUS-assigned VLAN
Shipping weight1.81 kg
Package size305 × 305 × 178 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What comes in the box with the U7-Pro-XG-Wall and what must be purchased separately?

The box includes the wall-mounted access point and mounting hardware; a PoE+ injector or switch providing 42.5-57V DC at up to 22W must be supplied separately.

Which wireless data rate version should I choose for the 6 GHz band?

The 6 GHz radio supports up to 5.8 Gbps using 320 MHz channels and MCS0-13 with 2x2 MIMO, matching the single hardware configuration offered.

What does the 5.8 Gbps 6 GHz figure mean once the AP is installed?

It represents the maximum PHY rate under ideal conditions with a 2x2 Wi-Fi 7 client on a 320 MHz channel; real-world throughput will be lower due to overhead, distance and interference.
