Lemon green LC duplex fibre cable 20m with ceramic ferrules

Enfain

Enfain LC-LC OM5 Duplex Fibre Optic Cable 20m Lemon Green

SKU CH-P8H1-9JDC9

A 20-metre lemon-green OM5 duplex patch cable with LC connectors on both ends, 50/125 µm multimode fibre, 3.0 mm PVC jacket.

Length 20m

  • Low insertion loss with repeatability under .1 dB
  • Easy network changes supported by exchangeability under .2 dB
  • Durable ceramic ferrules rated for over 1000 mating cycles
  • Safe for confined spaces with PVC jacket and LSZH option
  • Reliable across extreme environments from -40 to +80 degrees

Enfain LC-LC OM5 Duplex Cable

The Enfain LC-LC OM5 duplex cable is a 20 metre multimode fibre patch lead built for data-centre and enterprise links. It suits installers and network engineers who need reliable short-reach connections between transceivers, patch panels or switches. The lemon green jacket identifies the OM5 wideband class at a glance.

Ceramic ferrules and PVC LSZH jacket

Each end uses a ceramic ferrule rated for more than 1000 mating cycles, keeping insertion loss below .1 dB repeatability and .2 dB exchangeability. The 3.0 mm PVC outer skin is customisable to LSZH OFNP, providing flame-retardant, low-smoke performance for regulated indoor pathways. Dual-core construction carries transmit and receive fibres in a single assembly.

OM5 bandwidth headroom

The 50/125 micron core supports 10 GbE and higher speeds across the full 20 metre run with ample margin for future 40 GbE or 100 GbE short-reach standards. It is not suited for single-mode distances or outdoor plant installations where tighter bend radius or UV resistance are required.

Highlights

  • Low insertion loss with repeatability under .1 dB
  • Easy network changes supported by exchangeability under .2 dB
  • Durable ceramic ferrules rated for over 1000 mating cycles
  • Safe for confined spaces with PVC jacket and LSZH option
  • Reliable across extreme environments from -40 to +80 degrees

Specifications

No published specifications for this item yet.

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How many mating cycles can the ceramic ferrules on this LC-LC OM5 cable withstand before replacement?

The ceramic ferrules are rated for more than 1000 mating cycles, so replacement is only needed after very frequent re-patching.

What is the maximum insertion-loss increase allowed per connection on this OM5 duplex link?

Each LC connection adds less than 0.2 dB of insertion loss, which is the first limit reached when cascading multiple patches.

Does the PVC jacket stay within its temperature rating when the cable runs continuously in a 40 °C cabinet?

The jacket is rated from -40 °C to +80 °C, so 40 °C continuous operation is well inside the specified range.
