Analog Technologies High Voltage Power Supply 24V 6kV 1mA AHV24V6KV1MAW

SKU CH-22N2-S6N8Z

Compact 24 V DC-to-DC module delivers adjustable 0–6 kV at up to 1 mA with electronic shutdown

  • TypeHigh Voltage Power Supply

Options AHV24V6KV1MAW

  • Adjustable 0–6 kV output controlled by 0–5 V signal
  • 24 V DC input draws only 80–380 mA
  • Precise 5 V reference voltage with ±0.05 V tolerance
  • Full-span modulation enables continuous voltage control
  • Electronic shutdown provides instant output disable

High-Voltage DC-DC Module

This compact power supply converts a 24 V DC input into an adjustable 0 to 6 kV output with a maximum current of 1 mA. It targets engineers building X-ray sources, electrospinning rigs, or semiconductor inspection tools that need a precise high-voltage rail. The module accepts a control voltage of 0 to 5 V for full-span output modulation.

Replaces Bulky HV Racks

The unit replaces rack-mount high-voltage supplies when space, weight, or integration time are constraints. A jump to this module makes sense when the application demands 6 kV at low current and can tolerate a 24 V input rail with current draw between 80 mA and 380 mA. It is not for systems needing higher current, bipolar output, or mains-powered operation.

PCB-Mount Integration

Four mounting holes and a pin header allow direct soldering to a host board, so no external wiring harness is required. The 5 V reference output (±0.05 V) simplifies control-loop design, while the electronic shutdown pin adds a hardware safety interlock. Designers must provide adequate creepage and clearance on the PCB layout to meet 6 kV isolation requirements.

Highlights

  • Adjustable 0–6 kV output controlled by 0–5 V signal
  • 24 V DC input draws only 80–380 mA
  • Precise 5 V reference voltage with ±0.05 V tolerance
  • Full-span modulation enables continuous voltage control
  • Electronic shutdown provides instant output disable

Specifications

TypeHigh Voltage Power Supply

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What input voltage and current range does the AHV24V6KV1MAW require from the 24 V source?

The module operates from 24 V ± 1 V and draws between 80 mA and 380 mA depending on load.

How is the 0–6 kV output set, and what wiring mistake causes no output?

Apply a 0–5 V control signal to the CTRL pin; leaving CTRL floating or grounded keeps the output at 0 V.

Which onboard reference should be checked periodically to verify calibration stability?

The 5 V ± 0.05 V reference voltage; drift beyond this window indicates the module needs service.
