Compact silver metal box with screw terminals and label

Analog Technologies

Analog Technologies AHV12V6KV1MAW High Voltage Power Supply 6kV 1mA 24V

SKU CH-ZS8K-SSJZ3

Delivers 0 to 6 kV at 1 mA from a 24 V input with 0 to 5 V control and shutdown pin

  • TypeHigh Voltage Power Supply

Options 12V to 6000V 1mA

  • Adjustable 0–6 kV output for versatile high-voltage applications
  • 24 V DC input with 130–710 mA draw fits standard industrial supplies
  • 0–5 V control voltage enables precise linear regulation
  • Electronic shutdown pin allows remote on/off switching
  • Monitor output 0–1.5 V gives real-time voltage feedback

Compact 6 kV High-Voltage Module

This compact DC-DC converter accepts a 24 V input and delivers an adjustable 0 to 6 kV output at up to 1 mA. A 0 to 5 V control voltage sets the output across the full span, while a dedicated shutdown pin enables remote on/off switching. The module includes a 5 V reference and a 0 to 1.5 V monitor voltage for system integration. It is built for laboratory and industrial equipment requiring a stable, regulated high-voltage source.

Suited for Precision High-Voltage Applications

Engineers designing X-ray systems, spectral analysers, electrospinning rigs or capacitor-charging circuits will appreciate the linear regulation and low ripple. The 1 mA current limit makes it unsuitable for high-power deposition or particle-accelerator loads that demand sustained current beyond this level. Buyers needing more than 6 kV or higher output current should evaluate alternative modules.

Critical Spec: 1 mA Maximum Output Current

The 1 mA ceiling is the single parameter that determines whether this supply can drive your load. Verify that your application’s peak and continuous current draw stay within this limit before purchase.

Highlights

  • Adjustable 0–6 kV output for versatile high-voltage applications
  • 24 V DC input with 130–710 mA draw fits standard industrial supplies
  • 0–5 V control voltage enables precise linear regulation
  • Electronic shutdown pin allows remote on/off switching
  • Monitor output 0–1.5 V gives real-time voltage feedback

Specifications

TypeHigh Voltage Power Supply

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What input voltage and current range does the module require from the 24V supply?

The unit operates from 24V ± 1V DC and draws between 130mA and 710mA depending on load.

How is the output voltage set and what control signal is used for shutdown?

Output voltage 0–6kV is set by a 0–5V control voltage on the CTRL pin; a separate electronic shutdown pin enables remote on/off switching.

What ongoing checks or replacements are needed for the high-voltage output section?

Monitor the 0–1.5V monitor voltage to verify output stability; the 5V ± 0.05V reference should remain within tolerance for precise regulation.
