Small rectangular red plastic sensor with 2m grey cable attached

ZIBOO

ZIBOO WTB4S-3N1361 photoelectric sensor NPN 10-30V 2m cable

SKU CH-50NH-GGGTW MPN WTB4S-3N1361

Miniature photoelectric proximity sensor with background suppression, NPN output, 10–30 V DC supply and 2 m PVC cable

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Compact 12.2 × 41.8 × 17.3 mm housing fits tight spaces
  • Background suppression ignores objects beyond 180 mm range
  • PinPoint LED at 650 nm gives sharp 6.5 mm spot at 150 mm
  • NPN light-switching output handles 100 mA with 0.5 ms response
  • IP67 and IP66 rated for –40 °C to +60 °C operation

Compact photoelectric sensor for industrial

The ZIBOO WTB4S-3N1361 is a miniature photoelectric proximity sensor with background suppression. It operates on 10 V DC to 30 V DC supply voltage and provides an NPN light-switching output rated at 100 mA. The visible red PinPoint LED emits at 650 nm wavelength with a 6.5 mm spot size at 150 mm distance. Detection range spans from 10 mm to 180 mm with a response time under 0.5 ms.

IP67 and IP66 rated housing with fixed cable

The rectangular plastic housing measures 12.2 mm by 41.8 mm by 17.3 mm and weighs 30 g. Optics use PMMA material while the ABS body meets enclosure ratings IP67 and IP66 for dust and water protection. A 2 m PVC cable with 0.14 mm² conductor cross-section and 3.4 mm diameter carries three wires for power and signal. Circuit protection includes A, C and D types. Potentiometer adjustment offers five turns for precise range setting.

Verify voltage, output type

Ensure your control system accepts 10 V DC to 30 V DC input and can read an NPN switching signal. The fixed 2 m cable length may require extension or routing planning in larger cabinets. Operating temperature range covers –40 °C to +60 °C while storage extends to +75 °C. Switching frequency reaches 1,000 Hz for high-speed applications. Buyers needing PNP output or connectorised variants should select a different model.

Highlights

  • Compact 12.2 × 41.8 × 17.3 mm housing fits tight spaces
  • Background suppression ignores objects beyond 180 mm range
  • PinPoint LED at 650 nm gives sharp 6.5 mm spot at 150 mm
  • NPN light-switching output handles 100 mA with 0.5 ms response
  • IP67 and IP66 rated for –40 °C to +60 °C operation

Specifications

BrandSICK
ModelWTB4S-3N1361
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What is the maximum sensing range of the WTB4S-3N1361 photoelectric sensor?

The maximum sensing range is 180 mm with background suppression.

What are the housing dimensions and mounting requirements for this sensor?

The rectangular housing measures 12.2 mm wide, 41.8 mm high and 17.3 mm deep with an IP67 and IP66 enclosure rating.

How do you wire the 2 m cable and adjust the sensing distance?

Connect the 3-wire PVC cable (0.14 mm² cross-section) to a 10-30 V DC supply; adjust the 5-turn potentiometer for the 10-180 mm range.
