ZIBOO UFN3-70B413 Ultrasonic Sensor electrician tool
Ultrasonic sensor detects labels with 2 mm gap using fork-shaped housing, 10–30 V DC supply, PNP/NPN switching, IP65 aluminium enclosure, M8 connector
- TypeTest Equipment
- Color/FinishRed
- Item Count1 pack
- Selling UnitBox
- Parts3 Years
- Labor1 Year
- Ultrasonic label detection with 2 mm minimum object size
- Fork-shaped housing with 3 mm width and 69 mm depth
- Teach-in adjustment via plus/minus button for sensitivity
- IP65 enclosure rating protects against dust and water jets
- 10–30 V DC supply with PNP/NPN selectable output
Ultrasonic label sensor
The ZIBOO UFN3-70B413 uses an ultrasonic fork to detect labels on a web. It operates on 10 V DC to 30 V DC supply voltage and provides a PNP or NPN switching output with 100 mA maximum current. The aluminium housing measures 18 mm by 47.5 mm by 92.5 mm and carries an IP65 enclosure rating. A 4-pin M8 male connector completes the interface.
Suited for web-edge and splice detection
This sensor suits packaging lines that need to register transparent or opaque labels across a 3 mm fork width and 69 mm fork depth. It teaches set-points with plus/minus buttons in 2-point or dynamic mode. Buyers who require a through-beam or retro-reflective photoelectric principle should look at a different technology.
Minimum detectable object 2 mm
The specification lists a minimum detectable object of 2 mm for gap-between-labels and label-size detection. This single figure decides whether the sensor can resolve the label geometry on your line.
Highlights
- Ultrasonic label detection with 2 mm minimum object size
- Fork-shaped housing with 3 mm width and 69 mm depth
- Teach-in adjustment via plus/minus button for sensitivity
- IP65 enclosure rating protects against dust and water jets
- 10–30 V DC supply with PNP/NPN selectable output
Specifications
| Brand | ZIBOO |
|---|---|
| Model | UFN3-70B413 |
| Type | Test Equipment |
| Color/Finish | Red |
| Item Count | 1 pack |
| Selling Unit | Box |
| Parts | 3 Years |
| Labor | 1 Year |
Questions about this item
What comes in the box and do I need to buy a cable separately?
The box contains one ultrasonic sensor in a red aluminium housing. A 4-pin M8 male connector is built in, so you will need a matching M8 cable or plug to wire it to your 10–30 V DC supply.
The fork width is fixed at 3 mm — which label gaps can it actually detect?
The sensor detects gaps and labels down to 2 mm, so any label spacing of 2 mm or wider will be sensed reliably with the 3 mm fork opening.
What does the 100 mA switching current mean when I connect it to a PLC input?
The PNP or NPN output can sink or source up to 100 mA, enough to drive most PLC inputs directly without an intermediate relay.
