Red cylindrical M8 proximity switch with 2m cable

ZIBOO

ZIBOO IME08-02BNSZW2S NPN Proximity Switch 2mm M8 Electrician Tool

SKU CH-PHCR-VGQSG MPN IME08-02BNSZW2S

Flush-mount M8 cylindrical sensor detects metal at 2 mm range with NPN normally-open output and IP67-rated nickel-plated brass housing

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Detects metal at 2 mm range with 4000 Hz switching
  • IP67 enclosure resists dust and water in harsh environments
  • NPN normally-open output works with 10–30 V DC supplies
  • Nickel-plated brass M8 housing fits standard threaded mounts
  • 2 m PVC cable with 0.25 mm² conductors simplifies wiring

ZIBOO M8 Proximity Switch for Electricians

The ZIBOO IME08-02BNSZW2S is a cylindrical inductive proximity switch designed for industrial sensing tasks. It operates on a 10 V DC to 30 V DC supply with an NPN normally-open output. The 2 mm sensing range suits close-range metal detection in automated equipment. An IP67 enclosure rating protects internal electronics against dust and temporary immersion.

Verify Voltage and Wiring Before Installation

Confirm your control system provides a DC supply between 10 V and 30 V with ripple below 10 %. The sensor draws 10 mA and delivers up to 200 mA continuous current through a 3-wire PVC cable. Wiring must match the NPN output function and 2 V maximum voltage drop. A 100 ms power-up delay means the output is not immediate after supply voltage appears.

Flush Mounting in M8 Threaded Holes

The nickel-plated brass housing fits a standard M8 x 1 thread with a 34 mm thread length and 52 mm overall length. Flush installation allows the sensing face to sit level with surrounding metal. Tightening torque must not exceed 5 Nm to avoid housing damage. The 2 m cable with 0.25 mm² conductors routes directly to the controller without extra connectors.

Highlights

  • Detects metal at 2 mm range with 4000 Hz switching
  • IP67 enclosure resists dust and water in harsh environments
  • NPN normally-open output works with 10–30 V DC supplies
  • Nickel-plated brass M8 housing fits standard threaded mounts
  • 2 m PVC cable with 0.25 mm² conductors simplifies wiring

Specifications

BrandZIBOO
ModelIME08-02BNSZW2S
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What comes in the box and what else is needed to install the ZIBOO IME08-02BNSZW2S?

The box contains one proximity switch with a 2 m PVC cable already attached. You will need a 10–30 V DC power supply and an M8 mounting nut, which are not included.

How do I choose between the available versions of this M8 proximity switch?

This model is a single variant: NPN normally-open output, 2 mm flush sensing range, 4 000 Hz switching frequency, and IP67 rating. No other versions are offered under this part number.

What does the 2 mm sensing range mean when the switch is mounted on a machine?

The switch detects a standard target at up to 2 mm; the safe operating distance is 1.62 mm. It mounts flush in an M8 thread with a 34 mm thread length and requires a maximum tightening torque of 5 Nm.
