Galvanized steel wall-mount enclosure 15 by 12 by 6 inches solid cover captive screws

Wiegmann

Wiegmann SC121506G line protection enclosure 12x15x6 in

SKU CH-C2VV-NH943

Galvanized steel wall-mount enclosure rated NEMA 1 with screw-on solid cover, 12 by 15 by 6 inches, CSA and cULus listed

  • Galvanised steel construction protects indoor circuits
  • NEMA 1 rating suits dry indoor environments
  • CSA, cULus and UL listings confirm code compliance
  • Embossed mounting holes simplify wall installation
  • 12 × 15 × 6 in dimensions fit standard panel layouts

Galvanized Steel Wall Enclosure

The Wiegmann SC121506G is a NEMA 1 rated enclosure built from 16 gauge galvanized steel for indoor wall mounting. It provides a 12 inch by 15 inch by 6 inch housing with a solid screw-on cover for line protection components. Installers and facility managers use it to shield circuit breakers and wiring junctions from dust and incidental contact.

Thermal and Power Characteristics

The galvanized steel body and solid cover rely on natural convection to dissipate heat from installed breakers or terminals. No active cooling fans or vents are present, so the enclosure operates silently and adds no electrical load to the circuit. The 5.88 inch usable opening depth determines the maximum component profile that can be accommodated.

Included Hardware and Compliance

The package supplies self-tapping screws and plated steel cover screws for immediate assembly and secure closure. Embossed mounting holes simplify attachment to structural framing without separate brackets. The unit carries CSA Certified and cULus listings, confirming compliance with North American safety standards for electrical enclosures.

Highlights

  • Galvanised steel construction protects indoor circuits
  • NEMA 1 rating suits dry indoor environments
  • CSA, cULus and UL listings confirm code compliance
  • Embossed mounting holes simplify wall installation
  • 12 × 15 × 6 in dimensions fit standard panel layouts

Specifications

BrandWIEGMANN

Questions about this item

How is the SC121506G enclosure mounted to the wall?

The enclosure has embossed mounting holes for wall mounting and includes self-tapping screws for installation.

What maintenance will the galvanized steel finish require over time?

The galvanized finish protects the 16 ga steel from corrosion; inspect periodically for damage to the coating.

What is the usable internal depth limit for components inside this enclosure?

The usable opening depth is 5.88 in, which determines the maximum depth of installed components.
