Wiegmann RSC242408 Padlockable Hasp Electrical Enclosure 24 in H 24 in W 8 in D 14 ga

Wiegmann RSC242408 Padlockable Enclosure

The Wiegmann RSC242408 is a carbon steel electrical enclosure rated NEMA 3R for outdoor protection against rain and sleet. It measures 24 in high by 24 in wide by 8 in deep and is built from 14 ga steel with a painted gray finish. The solid screw-on cover includes a padlockable hasp for secure access. It is suited for installers mounting circuit breakers or line protection gear on exterior walls.

NEMA 3R rating and 14 ga steel construction

The NEMA 3R rating means the enclosure sheds falling water but is not sealed against dust or hose-directed spray. The 14 ga carbon steel provides mechanical rigidity for wall mounting yet lacks the corrosion resistance of stainless grades in salt-spray environments. The usable opening depth of 7.88 in limits the profile of internal components. The screw-on cover requires tools for routine opening.

24 by 24 inch footprint with 7.88 inch usable depth

The 24 by 24 inch interior footprint accommodates standard breaker panels and terminal blocks with room for wiring gutters. The 7.88 inch usable depth handles most DIN-rail devices and small contactors but cannot accept deep-frame moulded-case breakers or large transformers. The padlockable hasp secures the door against unauthorised entry while the included screws speed initial installation. Builders needing greater depth or a hinged door should specify a different series.
