Small red plastic rectangular sensor with cable and mounting bracket

Wenglor

Wenglor OTDK502A0091 reflex sensor PNP 500 mm range 10...30 V DC IP67

SKU CH-3A4E-GCRC0 MPN OTDK502A0091

PNP reflex sensor detects objects up to 500 mm with infrared light, 10...30 V DC supply, 500 Hz switching frequency and IP67-rated plastic housing

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 500 mm detection range with infrared light source
  • PNP switching output delivers up to 200 mA with short-circuit and overload protection
  • IP67 rated plastic housing withstands dust and water ingress
  • Potentiometer adjustment allows precise sensitivity setting
  • ..30 V DC supply voltage with reverse polarity protection

Industrial reflex sensor for 500 mm detection

The Wenglor OTDK502A0091 is a PNP reflex sensor designed for automated presence detection up to 500 mm. It operates on a 10...30 V DC supply and carries an IP67 rating for harsh environments. The unit suits machine builders and maintenance engineers who need reliable object sensing on conveyors or packaging lines.

Mounting console and 2 m cable included

A mounting console ships in the box so the sensor can be fixed immediately without separate brackets. The pre-wired 4-wire cable runs 2 m, removing the need to source and terminate a connector in the field. Both items reduce installation time compared with a bare sensor.

500 mm sensing range sets the application limit

The infrared beam detects objects out to 500 mm with a 5° opening angle and less than 15 % switching hysteresis. If the target must be sensed beyond this distance, the sensor will not reach it and a longer-range device is required.

Highlights

  • 500 mm detection range with infrared light source
  • PNP switching output delivers up to 200 mA with short-circuit and overload protection
  • IP67 rated plastic housing withstands dust and water ingress
  • Potentiometer adjustment allows precise sensitivity setting
  • ..30 V DC supply voltage with reverse polarity protection

Specifications

BrandWenglor
ModelOTDK502A0091
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

How long does the infrared light source last before it needs replacing?

The infrared emitter is rated for 100000 hours of service life at 25 °C ambient temperature.

At 500 Hz switching frequency, what is the first limitation during continuous operation?

The 1 ms response time sets the minimum cycle period, so the sensor cannot resolve events faster than one millisecond.

Does the plastic housing stay cool and quiet when running all day on 24 V DC?

Current draw stays below 30 mA at 24 V, so heat is minimal and the solid-state design produces no audible noise.
