Black plastic automotive circuit breaker 100A 30VDC

Velvac

Velvac 091007 100A 30VDC circuit breaker

SKU CH-VRRV-MEP1P

Manual-reset 100 A circuit breaker rated for 30 V DC auxiliary circuits, plug-in blade terminals, SAE J1625 compliant

  • TypeCircuit Breakers
  • Manual reset protects auxiliary circuits
  • 100 A rating handles high-current accessory loads
  • 30 V DC operation suits vehicle electrical systems
  • SAE J1625 compliance confirms automotive design
  • UL 94V-0 plastic housing resists heat and flame

Velvac 091007 100A 30VDC Breaker

The Velvac 091007 is a Type III series automotive circuit breaker rated at 100 amps and 30 volts DC. It features a plug-in mounting style with blade terminal connections for straightforward installation in compatible fuse panels. The housing is constructed from black UL 94V0 rated thermoset plastic measuring 1.0 inch high, 3.0 inches wide and 1.0 inch deep. It carries a 3kA interrupt rating at 30V DC and operates with a manual reset mechanism.

Suits auxiliary and accessory circuits requiring

This breaker suits auxiliary and accessory circuits where a manual reset function is preferred after an overload event. It is not for applications that require automatic cycling or push-to-trip operation. Builders needing a higher voltage rating or a different interrupt capacity should look at other devices. The SAE J1625 standard applies to its design and testing.

100A 30VDC rating with manual reset

The single specification that decides fitment is the 100 amp, 30 volt DC rating combined with the manual reset type. Verify that the circuit voltage does not exceed 30V DC and that the continuous current demand stays within 100 amps. The plug-in blade terminals must match the panel socket layout for a secure connection.

Highlights

  • Manual reset protects auxiliary circuits
  • 100 A rating handles high-current accessory loads
  • 30 V DC operation suits vehicle electrical systems
  • SAE J1625 compliance confirms automotive design
  • UL 94V-0 plastic housing resists heat and flame

Specifications

BrandVELVAC
TypeCircuit Breakers

Questions about this item

What plug-in panel or fuse block accepts the blade-terminal 100 A breaker?

The breaker uses a standard plug-in mount with blade terminals designed for SAE J1625 auxiliary and accessory circuit panels.

Will the manual-reset mechanism coordinate with lower-rated branch breakers already in the panel?

Its 3 kA interrupt rating at 30 V DC allows it to act as a main device while downstream branch breakers handle smaller overloads.

How can I verify the breaker has tripped after an overload event?

The manual reset button extends visibly when the 100 A thermal element opens, and must be pressed back in to restore power.
