White square relay with spade terminals

Value Brand

Value Brand 24V Coil Switching Relay hvac control

SKU CH-H3WQ-VMNYW

24 V coil switching relay for HVAC resistive loads, single-phase motors, solenoids and two-speed motors with 12 A at 120 V AC and 6 A at 240 V AC

  • 24 V coil voltage suits standard HVAC control circuits
  • DPDT contact form switches two separate circuits simultaneously
  • Silver-alloy contacts carry 12 A at 120 V AC resistive loads
  • 50/60 Hz rating matches mains frequency in most regions
  • Impact-modified PBT housing resists vibration and heat

24 V Coil Switching Relay for HVAC

The Value Brand 24 V coil switching relay handles resistive loads, single-phase motors, solenoids and two-speed motors. It uses a DPDT contact form with silver-alloy copper contacts on spade terminals. The coil operates at 50 or 60 Hz.

Check voltage and current ratings before ordering

Verify that the control circuit supplies 24 V AC at 50 or 60 Hz. Confirm the load does not exceed 12 A at 120 V AC or 6 A at 240 V AC. The locked-rotor rating is 60 A at 120 V AC. Ensure the square base and spade terminals match the existing socket.

Fits standard HVAC control panels with spade sockets

The square base plugs into common relay sockets, freeing DIN-rail space for other modules. Spade terminals allow quick wiring without soldering. The impact-modified PBT and reinforced PET housing resists vibration in furnace and air-handler cabinets.

Highlights

  • 24 V coil voltage suits standard HVAC control circuits
  • DPDT contact form switches two separate circuits simultaneously
  • Silver-alloy contacts carry 12 A at 120 V AC resistive loads
  • 50/60 Hz rating matches mains frequency in most regions
  • Impact-modified PBT housing resists vibration and heat

Specifications

BrandZORO SELECT

Questions about this item

Does the relay ship with any mounting hardware or wiring, or must those be sourced separately?

The relay is supplied as the switching unit only; mounting brackets, screws and wire leads are not included and must be purchased separately.

Which coil voltage version should be selected for a 24 V control circuit?

The listed model uses a 24 V coil, so it is the correct choice for a 24 V control circuit.

What does the 12 A rating at 120 V AC mean for actual motor or heater loads?

It indicates the relay can continuously switch resistive loads or single-phase motors up to 12 A at 120 V AC, with a locked-rotor inrush capacity of 60 A at the same voltage.
