Cylindrical chrome-plated brass inductive sensor with threaded M30×1.5 body and cable exit

Turck

Turck BC10-M30-VP4X 25020 Inductive Sensor PNP M30×1.5 10mm 10-65VDC 233g

SKU CH-Q722-YDC3Q MPN BC10-M30-VP4X

M30×1.5 inductive sensor detects metal at 10 mm, runs on 10-65 VDC with PNP complementary output, weighs 233 g

  • TypeTest Equipment
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • 10 mm flush switching distance detects metal targets reliably
  • M30 × 1.5 threaded barrel fits standard mounting holes
  • 10…65 VDC supply range suits varied control voltages
  • PNP complementary output simplifies wiring logic
  • Chrome-plated brass housing resists industrial wear

Industrial Inductive Sensor M30

The Turck BC10-M30-VP4X 25020 is a flush-mount inductive proximity sensor with a 10 mm rated switching distance. It features a chrome-plated brass threaded barrel sized M30 × 1.5 and weighs 233 g. The unit operates on a 10 to 65 VDC supply and provides a complementary PNP output via a cable connection. It carries cULus approval for industrial use.

Fine Adjustment Potentiometer

A built-in potentiometer allows precise adjustment of the switching point without replacing the sensor. This lets maintenance technicians calibrate the 10 mm sensing range to match specific target materials or mounting conditions. The complementary contact provides both normally open and normally closed signals from a single device. The DC 4-wire cable simplifies wiring in control cabinets.

Pre-Installation Checks

Verify that the mounting location accommodates an M30 × 1.5 threaded barrel and the sensor's overall length. Confirm the control system accepts a PNP complementary output and that the supply voltage falls within the 10 to 65 VDC range. Ensure the cable routing reaches the termination point without stress. The sensor is designed for flush mounting in metal.

Highlights

  • 10 mm flush switching distance detects metal targets reliably
  • M30 × 1.5 threaded barrel fits standard mounting holes
  • 10…65 VDC supply range suits varied control voltages
  • PNP complementary output simplifies wiring logic
  • Chrome-plated brass housing resists industrial wear

Specifications

BrandTURCK
ModelBC10-M30-VP4X 25020
TypeTest Equipment
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

How often will the M30×1.5 threaded barrel need replacement under normal use?

The sensor has no user-serviceable parts; the chrome-plated brass housing is designed for the life of the installation.

At what switching distance does the 10 mm rated range become unreliable during continuous operation?

The rated switching distance is 10 mm flush; performance stays within specification as long as supply voltage remains between 10 and 65 VDC.

How much heat does the 233 g housing dissipate when the PNP output runs all day at 65 VDC?

The metal CuZn body acts as a heat sink; no external cooling is required for continuous operation within the 10…65 VDC range.
