White plastic desktop switch with five RJ45 ports on the front and a power socket on the side

TP-Link

TP-Link TL-SG1005D 5-port Gigabit network switch

SKU CH-24EE-T5E1V MPN TL-SG1005D

Adds five Gigabit RJ45 ports with auto-negotiation and flow control, saving up to 85% power in a fanless desktop or wall-mount case

  • Switch TypeNetwork Switch
  • FormatDesktop
  • StandardsIEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
  • Network Management TypeUnmanaged
  • Primary Ports5 x RJ45
  • Primary Port Speed10/100/1000Mbps

Model TL-SG1005D

Show 2 more configurations

Primary Port 5 Port

  • Plug-and-play setup needs no configuration or software
  • Five gigabit ports expand wired network capacity
  • Green Ethernet technology saves up to 85% power
  • Fanless design runs silent on the desktop
  • IEEE 802.3x flow control ensures reliable data transfer

Five-port Gigabit switch for desktop use

The TP-Link TL-SG1005D adds five 10/100/1000Mbps RJ45 ports to a network with no configuration required. It operates silently thanks to a fanless plastic enclosure that can sit on a desk or be mounted on a wall. An external 9VDC 0.6A power adapter is included in the package.

Unmanaged operation with auto-negotiation

Every port supports auto-negotiation and Auto MDI/MDIX, so straight-through cables work in any combination. The switch follows IEEE802.3, IEEE802.3u, IEEE802.3ab and IEEE802.3x standards and provides flow control for reliable data transfer. Maximum power draw is 3W at 220V.

Ideal for small wired expansions

Home users and small offices needing a few extra wired connections for PCs, consoles or printers will find this switch simple and cost-effective. Buyers who need managed features such as VLANs, QoS or port monitoring should look at a managed model instead. Builds requiring more than five ports or PoE power delivery will also need a different unit.

Highlights

  • Plug-and-play setup needs no configuration or software
  • Five gigabit ports expand wired network capacity
  • Green Ethernet technology saves up to 85% power
  • Fanless design runs silent on the desktop
  • IEEE 802.3x flow control ensures reliable data transfer

Specifications

BrandTP-Link
SeriesPlug and Play
ModelTL-SG1005D
Switch TypeNetwork Switch
FormatDesktop
StandardsIEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
Network Management TypeUnmanaged
Primary Ports5 x RJ45
Primary Port Speed10/100/1000Mbps
ProtocolsTCP/IP
PowerPower Consumption Maximum: 3W (220V/50Hz)
External Power Supply External Power Adapter: (Output: 9VDC / 0.6A)
Features5 Gigabit Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
Green Ethernet technology saves the power up to 85%
IEEE 802.3x flow control provides reliable data transfer
Plastic case, desktop or wall-mounting design
Plug and play, no configuration required
Dimensions0.90" x 5.50" x 3.50"
Weight0.75 lb.
TemperatureOperating Temperature: 0 degree C ~ 40 degree C (32 degree F ~ 104 degree F)
Storage Temperature: -40 degree C ~ 70 degree C (-40 degree F ~ 158 degree F)
HumidityOperating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
Package Contents5-Port Gigabit Desktop Switch TL-SG1005D
Power Adapter
Installation Guide
Shipping weight0.27 kg
Package size191 × 124 × 97 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the 1000 Mbps port speed actually deliver when I plug in my PC?

Each of the five RJ45 ports auto-negotiates at 10, 100 or 1000 Mbps, so a connected PC will run at its own NIC’s maximum up to Gigabit line rate.

Which Ethernet standards limit the switch’s real-world throughput?

It complies with IEEE802.3, IEEE802.3u and IEEE802.3ab, capping each port at 1000 Mbps full-duplex with IEEE802.3x flow control.

How much clearance do I need on a desk or wall for the plastic case?

The unit measures 0.90" high, 5.50" wide and 3.50" deep, and includes wall-mount slots for vertical or horizontal mounting.
