Red rectangular digital luminance meter with LCD display and cosine-corrected sensor, 100 by 60 by 27 mm

TES Electrical Electronic Corp.

TES Electrical Electronic Corp. TES-1330A Digital Luminance Meter 20/200/2000/20000 Lux Cosine Corrected

SKU CH-5NH5-ST1BE MPN TES-1330A

Measures light from 20 to 20000 Lux with cosine correction and 0.01 Lux resolution

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Accurate readings across four ranges from 20 to 20000 Lux
  • Cosine angular correction ensures reliable off-axis light measurement
  • Spectral sensitivity matches the CIE photopic curve for true luminance data
  • Data hold and peak hold functions freeze readings for easy recording
  • Compact 135 x 72 x 33 mm design with carrying case for portability

Portable light meter for site surveys

The TES-1330A is a handheld luminance meter built for electricians, lighting installers and facility managers who need quick illuminance checks. It covers four ranges from 20 to 20000 Lux with a 3 1/2 digit LCD readout. Cosine angular correction keeps readings accurate when light hits the sensor off-axis. A data-hold button freezes the display for note-taking.

Thermals noise and power draw

The unit draws only a few milliwatts from a single 9V battery, so it runs cool and silent during extended surveys. No fan or active cooling is present, meaning zero acoustic disturbance in quiet environments. Operating temperature spans 0 to 40 °C with humidity below 70% RH. The low current draw supports long sessions without frequent battery swaps.

Bundled accessories and their impact

A fitted carrying case protects the meter and sensor during transport between job sites. The included 9V cell lets you start measuring immediately on arrival. An instruction manual explains range selection, hold functions and the analog output jack for external logging. These items remove the need to source power or protection separately.

Highlights

  • Accurate readings across four ranges from 20 to 20000 Lux
  • Cosine angular correction ensures reliable off-axis light measurement
  • Spectral sensitivity matches the CIE photopic curve for true luminance data
  • Data hold and peak hold functions freeze readings for easy recording
  • Compact 135 x 72 x 33 mm design with carrying case for portability

Specifications

BrandTES
ModelTES-1330A
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

How do I install the 9V battery in the TES-1330A and what step is often missed?

Open the battery compartment on the rear, insert one 9V battery observing polarity, then close the cover securely; the step often missed is confirming the low-battery indicator is off before starting measurements.

What maintenance will the TES-1330A need over time?

Replace the 9V battery when the low-battery symbol appears, wipe the cosine-corrected sensor window with a soft dry cloth, and store the unit in its carrying case at 0 to 40 °C below 70 % RH to maintain ±2 % repeatability.

What limit appears first during continuous use of the TES-1330A?

The 20000 Lux range tops out first — readings above full scale show only the highest digit (1) and the analog recorder output saturates at DC 2 V, so higher illuminance cannot be captured until light levels drop.
