Tempco TEC16001 temperature controller, transparent square 1/16 DIN housing, red LED display

Tempco

Tempco TEC16001 Temperature Controller 90-250V Relay 2A 1/16 DIN hvac control

SKU CH-J9F9-4QTR0

Programmable 1/16 DIN temperature controller with SPDT relay output for 90-250V AC systems

  • ColorTransparent
  • Universal sensor input fits many HVAC applications
  • Wide 90-250V AC supply suits global installations
  • 2A SPDT relay output switches loads directly
  • Compact 1/16 DIN size saves panel space
  • CE, CSA, FM and UL certified for safety compliance

Digital Temperature Controller for HVAC Systems

The Tempco TEC16001 is a 1/16 DIN digital temperature controller designed for HVAC applications. It accepts a universal sensor input and operates on a 90 to 250V AC supply. A single red LED display shows the process value clearly. The unit carries CE, CSA, FM and UL certifications.

Thermals Noise and Power Draw

Power consumption is rated at 10 VA during normal operation. The SPDT relay output switches loads up to 2 A without generating audible noise. No internal fan is present so the controller runs silently in the panel. Heat dissipation remains low inside the 1.87 by 3.75 inch enclosure.

Upgrade Path and Fit

This controller replaces older analogue limit controllers that lack a digital readout or universal sensor compatibility. The jump is worthwhile when precise setpoint visibility and flexible sensor choice are required. It does not suit installations needing alarm outputs or proportional control modes. Builders who need a second relay output should look elsewhere.

Highlights

  • Universal sensor input fits many HVAC applications
  • Wide 90-250V AC supply suits global installations
  • 2A SPDT relay output switches loads directly
  • Compact 1/16 DIN size saves panel space
  • CE, CSA, FM and UL certified for safety compliance

Specifications

BrandTEMPCO
ColorTransparent

Questions about this item

How do I wire the 90-250V AC supply and the 2A relay output into a 1/16 DIN panel cut-out?

Mount the 1.87 x 1.87 in controller in the DIN cut-out, connect line and neutral to the 90-250V AC terminals, then wire the load to the SPDT relay contacts rated at 2A, observing the 10 VA power rating.

Which components of the TEC16001 will need replacement after extended service?

The electromechanical relay is the primary wear item; its contacts degrade with switching cycles, so plan to replace the controller when the 2A relay no longer closes reliably.

What is the first limitation reached when the controller runs continuously at full 2A load?

The 10 VA internal power budget and the relay’s 2A contact rating are the limiting factors; sustained operation at the maximum 2A load will hit the relay’s current ceiling first.
