Compact silver box with front push buttons and rear VGA USB ports

STARTECH

STARTECH SV231USB 2-port USB VGA KVM switch

SKU CH-P4M7-9D3EG MPN SV231USB

Control two computers from one monitor, keyboard and mouse with front-panel switching and a built-in three-port USB hub

  • TypeD-Sub, USB
  • PC Connectors2 x USB B (4 pin) Female 2 x VGA (15 pin; High Density D-Sub
  • Console Connectors1 x VGA (15 pin; High Density D-Sub) Female 3 x USB A (4 pin
  • Computer Connections2 Ports
  • Monitor Connections1 Port
  • Video Resolution1920 x 1440

Computer Connections 2 Ports

Style Single Monitor - USB Cables Included

  • Control 2 computers from one keyboard, mouse and monitor
  • Built-in 3-port USB hub shares peripherals between systems
  • Front-panel push buttons give instant computer selection
  • Auto-scan cycles at 3, 8, 15 and 30 second intervals
  • Supports 1920 x 1440 video resolution for sharp display

Dual-computer VGA KVM with USB hub

The StarTech SV231USB is a two-port KVM switch that lets one VGA monitor, USB keyboard and USB mouse control two computers. It includes two combined USB and VGA cables plus a power adapter, so the kit is ready to connect immediately. The unit suits office desks, digital-signage servers or manufacturing-line PCs where space and peripheral count must stay low.

VGA 1920 x 1440 and USB 3-port sharing

Video passes through a single 15-pin high-density D-Sub console port at up to 1920 x 1440 resolution, which is the practical ceiling of the analogue VGA interface. A built-in three-port USB Type-A hub shares printers, scanners or storage across both systems without extra cabling. Switching between computers is done by front-panel push buttons or by automatic scanning at intervals of 3, 8, 15 or 30 seconds. The switch operates independently of the host operating systems.

Check VGA outputs and USB keyboard/mouse

Before ordering, verify that each target computer provides a VGA video output and at least one USB Type-B port for the included cables. The console side needs a VGA-input monitor and USB peripherals with Type-A plugs. Buyers who need digital video such as HDMI or DisplayPort, or who require more than two computer ports, will need a different KVM solution.

Highlights

  • Control 2 computers from one keyboard, mouse and monitor
  • Built-in 3-port USB hub shares peripherals between systems
  • Front-panel push buttons give instant computer selection
  • Auto-scan cycles at 3, 8, 15 and 30 second intervals
  • Supports 1920 x 1440 video resolution for sharp display

Specifications

BrandStarTech.com
ModelSV231USB
TypeD-Sub, USB
PC Connectors2 x USB B (4 pin) Female
2 x VGA (15 pin; High Density D-Sub) Male
Console Connectors1 x VGA (15 pin; High Density D-Sub) Female
3 x USB A (4 pin) Female
Computer Connections2 Ports
Monitor Connections1 Port
Video Resolution1920 x 1440
PC SelectionPush Buttons
AutoScan Interval3, 8, 15 and 30 seconds
ApplicationDual system control for a single workstations increasing user productivity in the office
Provide centralized control for multiple high-res Digital Signage server control
Great for manufacturing line computer control, simplifying access to multiple systems
Perfect for PC test/burn-in computer control saving the desk space required for two monitors, keyboards and mice
FeaturesControl 2 computers from one USB keyboard/mouse/monitor
Share 3 different USB peripherals using the integrated hub
High 1920 x 1440 resolution capability
Front panel push buttons for easy computer selection
OS independent - No software or drivers required
Supports keyboard and mouse plug and play
Selectable auto scan time interval
Supports DDC2B VGA monitors
USB self-power operation
Dimensions2.80" x 4.90" x 1.60"
Weight14.80 oz.
Package Contents1 x 2 Port USB KVM Switch
2 x 2 IN 1 USB/VGA Cables
1 x Power Adapter
1 x Manual
Shipping weight1.59 kg
Package size239 × 183 × 97 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What resolution does the SV231USB support for the connected monitor?

The switch handles up to 1920 x 1440 resolution on the single VGA console port.

How do I switch between the two connected computers?

Front panel push buttons select the active system; an autoscan mode cycles every 3, 8, 15 or 30 seconds.

What USB ports are available for peripherals?

The console side provides three USB A female ports for keyboard, mouse and other USB devices.
