Aluminium clevis bracket, 50 mm bore, 65 mm long, silver finish

SPEEDAIRE

SPEEDAIRE 5VME3 Clevis Bracket 50 mm

SKU CH-DGWT-P58F3

Aluminium clevis bracket mounts 50 mm bore cylinders with 32 mm hole centres, 65 mm length and 27 mm height, supplied with retaining rings, bolts, pins and lock nut

  • Clevis bracket fits 50 mm bore cylinders
  • Aluminium body keeps weight down
  • 65 mm overall length suits compact installs
  • 32 mm hole centres match standard mounts
  • Includes retaining rings, bolts, pins and lock nut

Clevis Bracket for 50 mm Bore

This SPEEDAIRE clevis bracket mounts to cylinders with a 50 mm bore diameter. The aluminum body measures 65 mm overall length and 27 mm overall height. It is designed for metric pneumatic systems requiring a pivoting connection.

Included Retaining Rings, Bolts, Pins and Lock Nut

The package supplies two retaining rings, four bolts, four pins and a lock nut with pin. These components secure the bracket to the cylinder and the mounting surface without separate hardware sourcing. The bolt pattern uses a 32 mm center-to-center width.

Metric Dimensions Limit Interchangeability

The 50 mm bore specification and 32 mm mounting pattern restrict use to matching metric cylinders. Builders working with imperial bore sizes or different hole spacings cannot install this bracket without modification. The 65 mm overall width also defines the minimum clearance envelope.

Highlights

  • Clevis bracket fits 50 mm bore cylinders
  • Aluminium body keeps weight down
  • 65 mm overall length suits compact installs
  • 32 mm hole centres match standard mounts
  • Includes retaining rings, bolts, pins and lock nut

Specifications

BrandSPEEDAIRE

Questions about this item

Will the retaining rings or pins need periodic replacement on the 50 mm clevis bracket?

The kit includes two retaining rings, four bolts, four pins, a lock nut and a pin; replace any piece if wear or corrosion appears during inspection.

What is the first dimensional limit reached when the bracket is under continuous load?

The mount hole centre-to-centre width is fixed at 32 mm, so alignment tolerance is the limiting factor under sustained stress.

Does the aluminum body heat up or make noise during all-day compressor operation?

The bracket is a static aluminum mounting component; it generates no noise and its temperature follows the surrounding cylinder.
