Aluminium cylinder clevis mount, 5 in bore, silver finish

SPEEDAIRE

SPEEDAIRE 36NK64 Cylinder Clevis Mounting Hardware 5 in

SKU CH-CEQE-N1B7F

Clevis mounting hardware fits 5 in bore cylinders and includes retaining rings, screws and a clevis pin

  • Clevis mount fits 5 in bore cylinders
  • Detachable cap allows quick cylinder removal
  • Aluminium body resists corrosion in compressed-air systems
  • Includes retaining rings, screws and clevis pin for complete installation
  • 25 in hole centres match standard Speedaire mounting patterns

Clevis Mount for 5 Inch Bore

The SPEEDAIRE 36NK64 is a detachable clevis bracket designed to secure a cylinder with a 5 inch bore diameter. It suits maintenance teams and machine builders who need a reliable pivot mounting point for pneumatic or hydraulic actuators. The aluminium body keeps the assembly light while providing adequate strength for standard industrial duty. Included retaining rings, screws and a clevis pin allow immediate installation without sourcing separate hardware.

Inch-Based Dimensions and Fixed Geometry

All critical dimensions are expressed in inches, so the bracket fits only imperial-specification cylinders and matching rod ends. The mount hole centre-to-centre width is 1.25 in, fixing the pivot spacing and limiting compatibility to cylinders with that exact hole pattern. Overall length, width and height are fixed at 5 1/2 in by 5 1/2 in by 2 5/8 in, leaving no adjustment for misaligned structures. Builders working in metric systems or with non-standard hole centres cannot use this part.

Bore Diameter Determines Fit

The single specification that decides suitability is the 5 inch cylinder bore diameter. If the actuator bore differs from this value the bracket will not align with the cylinder cap or head mounting faces. No other dimension can compensate for a bore mismatch. Select this hardware only when the cylinder bore is exactly 5 in.

Highlights

  • Clevis mount fits 5 in bore cylinders
  • Detachable cap allows quick cylinder removal
  • Aluminium body resists corrosion in compressed-air systems
  • Includes retaining rings, screws and clevis pin for complete installation
  • 25 in hole centres match standard Speedaire mounting patterns

Specifications

BrandSPEEDAIRE

Questions about this item

Which SPEEDAIRE clevis mounting kit matches a 5 in bore cylinder?

The 36NK64 is made for a 5 in bore and includes the clevis bracket pin, two retaining rings and four screws needed for installation.

What does the 5 1/2 in overall length mean when the clevis is fitted to the cylinder?

That measurement is the total length of the cap detachable clevis once bolted on, so allow at least 5 1/2 in of clearance along the cylinder axis.

How does the 1.25 in mount hole centre-to-centre width limit the bolts I can use?

The bracket holes are spaced 1.25 in apart, so only bolts or pins with that exact centre distance will line up with the cylinder mount.
