Galvanised steel inline duct fan, 10 in diameter, rectangular housing with mounting bracket

Soler and Palau

Soler and Palau PV-250X 10 in Inline Centrifugal Duct Fan

SKU CH-XC2H-3SMAZ

Inline centrifugal duct fan moves 618 cfm at zero static pressure through 10 in ducting with a 214 W motor rated IP44 and 120V single-phase power

  • Delivers 618 cfm airflow at zero static pressure
  • 214 W motor output powers demanding ventilation tasks
  • IP44 motor rating resists dust and water splashes
  • Galvanised steel housing withstands 140 °F inlet air temperatures
  • Includes mounting bracket for straightforward 10 in duct installation

Built for 10-inch duct runs

The Soler and Palau PV-250X is an inline centrifugal duct fan designed for general-purpose ventilation where a 10-inch diameter connection is required. It suits installers and facility managers who need a single-speed unit that mounts directly in the duct line. Buyers who need variable airflow or a different duct diameter should look elsewhere.

Motor runs at 3 045 RPM with IP44 protection

The 214 W motor delivers 618 cfm at .000 in SP on 120 V AC single-phase power and is rated for inlet air up to 140 Degrees F. An IP44 enclosure protects internal parts from splashing water and solid objects larger than 1 mm. No speed control is included, so the fan operates at fixed output whenever powered.

Galvanized steel housing with mounting bracket

The housing is made from galvanized steel for corrosion resistance in typical indoor environments. A mounting bracket is supplied in the box to simplify attachment to joists or wall framing. No additional controls, duct adapters or wiring accessories are bundled.

Highlights

  • Delivers 618 cfm airflow at zero static pressure
  • 214 W motor output powers demanding ventilation tasks
  • IP44 motor rating resists dust and water splashes
  • Galvanised steel housing withstands 140 °F inlet air temperatures
  • Includes mounting bracket for straightforward 10 in duct installation

Specifications

BrandSOLER & PALAU

Questions about this item

How do I install the PV-250X inline fan and which step is often missed?

Mount the unit using the included bracket, connect 10 in ducting to the 8 1/8 in housing spigots, and wire the 120V AC supply; the step often missed is sealing every joint so static pressure stays near .000 in for the rated 618 cfm.

What maintenance or replacement will the PV-250X need over time?

Periodically clean the galvanized steel housing and impeller to maintain airflow, and plan to replace the 214 W single-speed motor if its IP44 protection degrades or bearings become noisy after extended use.

What is the first limit the PV-250X hits during sustained operation?

The maximum inlet air temperature of 140 Degrees F is the primary limit; exceeding it risks motor overheating because the unit lacks a high-efficiency motor and has only one fixed speed of 3,045 RPM.
