Siemens FXD63B250 molded case circuit breaker, three-pole, grey enclosure

SIEMENS

SIEMENS FXD63B250 Molded Case Circuit Breaker 250A 3 Pole

SKU CH-WMS1-DP3VN

Molded-case circuit breaker rated 250 A with a 22 kA interrupting capacity at 600 V AC and 500 V DC, three-pole thermal-magnetic trip

  • 250 A rated current for high-capacity three-phase circuits
  • 600 V AC and 500 V DC voltage ratings suit mixed-power systems
  • 22 kA interrupting rating at 600 V AC handles large fault currents
  • Thermal-magnetic trip with fixed 250 A instantaneous setting provides reliable overload and short-circuit protection
  • Free-standing mount with lug terminals simplifies installation in SB switchboards and Sentron panelboards

Industrial circuit protection for 250

The SIEMENS FXD63B250 is a molded case circuit breaker rated for 250 A continuous current on three poles. It uses thermal-magnetic trip units with fixed instantaneous settings and a high amp trip point of 250 A. The breaker fits Sentron panelboards and SB switchboards without lugs using terminal connection lugs and free-standing mounting. It is built for commercial and industrial power distribution where standard interruption is required.

Interruption capacity limited to 22 kA at 600 V AC

The breaker carries a maximum AIR rating of 22 kA at 600 V AC, which defines the highest prospective fault current it can safely interrupt on three-phase AC supplies. For DC circuits the rating is 500 V DC with the same frame. Installations with available fault current above 22 kA at 600 V AC need a higher-rated device. The fixed instantaneous trip cannot be adjusted to coordinate with downstream breakers beyond the published curve.

Fixed thermal-magnetic trip at 250 A decides

Both low and high amp trip settings are fixed at 250 A, so the breaker cannot be field-adjusted for different load profiles or selective coordination schemes. Choose this model only when the design calls for a 250 A frame with non-adjustable thermal-magnetic protection on three phases. Buyers who need adjustable trip settings or a different frame size must select another breaker.

Highlights

  • 250 A rated current for high-capacity three-phase circuits
  • 600 V AC and 500 V DC voltage ratings suit mixed-power systems
  • 22 kA interrupting rating at 600 V AC handles large fault currents
  • Thermal-magnetic trip with fixed 250 A instantaneous setting provides reliable overload and short-circuit protection
  • Free-standing mount with lug terminals simplifies installation in SB switchboards and Sentron panelboards

Specifications

BrandSIEMENS

Questions about this item

Should I choose the 250 A frame size or a different ampere rating for my panel?

This breaker has a fixed 250 A frame and identical high and low trip settings of 250 A, so it only fits applications that require that exact rating.

What does the 22 kA rating at 600 V AC mean for my installation?

It is the maximum interrupting capacity — the breaker can safely clear a fault current up to 22 kA on a 600 V AC system without damage.

Does the thermal-magnetic trip unit work on both AC and DC circuits?

Yes, the thermal-magnetic trip operates at 600 V AC and 500 V DC, and the breaker carries a 22 kA AIR rating at 600 V AC.
