Cylindrical M18 photoelectric sensor, plastic housing, 2 m PVC cable

Sick

Sick VTF18-4P5612 NPN Photoelectric Proximity Sensor electrician tool

SKU CH-8ZJ1-2B97M MPN VTF18-4P5612

NPN photoelectric proximity sensor with background blanking, M18 cylindrical housing, 45 mm sensing range, 10–30 V DC supply, IP67 rated, 2 m PVC cable

  • NPN output simplifies wiring for standard PLC inputs
  • 45 mm sensing range detects objects at close distance
  • IP67 enclosure resists dust and water ingress
  • 250 Hz switching frequency supports fast automation cycles
  • 10–30 V DC supply works with common control voltages

Industrial photoelectric sensor

The Sick VTF18-4P5612 is a cylindrical NPN photoelectric proximity sensor built for industrial automation. It uses background blanking to ignore objects beyond the set range. The M18 threaded housing fits standard mounting points on conveyors or machine frames.

10–30 V DC supply range

Operation requires a DC supply between 10 V and 30 V with ripple below 10 %. The four-wire PVC cable runs two metres and carries 0.14 mm² conductors. Switching frequency reaches 250 Hz with a 2 ms response time. Output current is limited to 100 mA.

45 mm sensing distance

Reliable detection covers 0 mm to 45 mm using an infrared LED spot of 3 mm at 25 mm. The focused optics and fixed adjustment suit consistent part positioning. IP67 enclosure and –25 °C to +70 °C temperature range allow use in wet or dusty environments. Not suited for applications needing longer range or adjustable sensitivity.

Highlights

  • NPN output simplifies wiring for standard PLC inputs
  • 45 mm sensing range detects objects at close distance
  • IP67 enclosure resists dust and water ingress
  • 250 Hz switching frequency supports fast automation cycles
  • 10–30 V DC supply works with common control voltages

Specifications

BrandSICK
ModelVTF18-4P5612

Questions about this item

Should I pick the 45 mm or 50 mm sensing range version?

This model has a single sensing range of 0 mm to 45 mm with a maximum of 50 mm; there are no alternate range versions to choose.

What does the 250 Hz switching frequency mean when the sensor is installed on a conveyor?

The sensor can detect up to 250 objects per second, so items passing the 3 mm light spot at 25 mm distance must not exceed that rate.

How does the M18 x 1 thread and 4-wire cable connect to a standard DC control input?

The M18 x 1 housing threads into an M18 mounting hole; the 2 m PVC cable with 0.14 mm² conductors carries 10–30 V DC supply and a PNP output up to 100 mA.
