Cylindrical angled plastic photoelectric proximity sensor with M12 connector

Sick

Sick VTF18-3N1840 Photoelectric Proximity Sensor NPN

SKU CH-FPC4-MK3KJ

Photoelectric proximity sensor detects objects from 3 mm to 90 mm using infrared LED, NPN dark-switching output, M12 connector, and IP67-rated plastic housing

  • Detects objects up to 100 mm using infrared LED
  • NPN dark-switching output responds in 2 ms
  • Potentiometer allows easy sensitivity adjustment
  • IP67 enclosure resists dust and water ingress
  • Operates reliably from –25 °C to +70 °C

Sick VTF18-3N1840 Sensor

The Sick VTF18-3N1840 is a photoelectric proximity sensor designed for industrial detection tasks. It operates on a 10 V DC to 30 V DC supply and provides an NPN dark-switching output. The unit suits automation engineers who need reliable object detection at short range.

Cylindrical Angled Housing

The sensor features a cylindrical angled housing made of plastic with PMMA optics. It carries an IP67 enclosure rating for dust and water protection. Connection is via a male M12 4-pin connector. A potentiometer allows on-site adjustment of the sensing range.

Check Voltage And Connector

Verify that your control system supplies 10 V DC to 30 V DC and accepts an NPN dark-switching signal. Ensure an M12 4-pin cable or matching junction block is available. Confirm the 3 mm to 90 mm sensing window fits the application. The sensor operates from –25 °C to +70 °C.

Highlights

  • Detects objects up to 100 mm using infrared LED
  • NPN dark-switching output responds in 2 ms
  • Potentiometer allows easy sensitivity adjustment
  • IP67 enclosure resists dust and water ingress
  • Operates reliably from –25 °C to +70 °C

Specifications

BrandSICK
ModelSICK VTF18-3N1840

Questions about this item

What supply voltage range does the VTF18-3N1840 sensor accept?

The sensor operates on 10 V DC to 30 V DC with a maximum ripple of 10 % and draws up to 30 mA.

What are the housing dimensions and mounting style of the VTF18-3N1840?

It has a cylindrical angled housing 75 mm in size, made of plastic with PMMA optics, rated IP67 for dust and water protection.

How is the VTF18-3N1840 wired and what adjustment does it use?

It connects via a 4-pin M12 male connector and uses a potentiometer for sensitivity adjustment; ensure the NPN dark-switching output matches your PLC input.
