Sick
Sick VTE18-4P4812 Photoelectric Proximity Sensor PNP
Photoelectric proximity sensor detects objects from 5 mm to 350 mm using infrared light with a selectable PNP output and IP67-rated cylindrical housing
- Reliable detection up to 350 mm with energetic photoelectric principle
- Operates on 10 V DC to 30 V DC supply voltage
- PNP output with selectable light or dark switching mode
- IP67 enclosure rating withstands dust and water ingress
- Compact M18 cylindrical housing just 60.6 mm long
Sick VTE18-4P4812 Proximity Sensor
The Sick VTE18-4P4812 is a cylindrical photoelectric proximity sensor designed for industrial detection tasks. It operates on a 10 V DC to 30 V DC supply and provides a PNP switching output with selectable light or dark switching via an L/D control cable. The sensor suits automation engineers and maintenance technicians who need reliable object detection in a compact M18 housing.
Upgrade From Basic Limit Switches
This sensor replaces mechanical limit switches or older diffuse sensors that lack the 5 mm to 350 mm sensing range and 250 Hz switching frequency. The jump is worth it when non-contact detection reduces wear, when the IP67 enclosure rating is required for wash-down environments, or when the 2 ms response time improves cycle speeds on packaging or conveying lines.
Straightforward M18 Installation
The sensor mounts via its M18 x 1 thread and connects through a 2 m, 4-wire PVC cable with 0.14 mm² conductors. No potentiometer adjustment is needed, so setup consists of aligning the radial optical axis and selecting the switching mode via the L/D wire. Common issues include exceeding the 100 mA output current, routing the cable where it can be pinched, or supplying voltage outside the 10 V DC to 30 V DC range.
Highlights
- Reliable detection up to 350 mm with energetic photoelectric principle
- Operates on 10 V DC to 30 V DC supply voltage
- PNP output with selectable light or dark switching mode
- IP67 enclosure rating withstands dust and water ingress
- Compact M18 cylindrical housing just 60.6 mm long
Specifications
| Brand | SICK |
|---|---|
| Model | SICK VTE18-4P4812 |
Questions about this item
What thread diameter does the M18 housing need for mounting?
The sensor uses an M18 x 1 thread diameter for cylindrical mounting.
How is the light/dark switching mode selected on the 4-wire cable?
Connect or disconnect the L/D control wire to choose between light and dark switching.
When should the PVC cable be inspected or replaced?
Check the 2 m PVC cable for cuts or abrasion if the IP67 enclosure is compromised.
