Cylindrical plastic photoelectric sensor with 2 m PVC cable and potentiometer adjustment

Sick

Sick VTE18-4N2812 Photoelectric Proximity Sensor NPN

SKU CH-Y76C-6NESQ

Photoelectric proximity sensor detects objects from 3 mm to 170 mm using infrared LED with adjustable potentiometer, NPN output, IP67 rating, and 2 m PVC cable

  • Detects objects up to 200 mm with infrared LED
  • Adjustable sensing range from 3 mm to 170 mm via potentiometer
  • Selectable light or dark switching through control cable
  • Operates reliably from –25 °C to +70 °C in IP67 housing
  • Connects directly with 2 m PVC cable at 10–30 V DC

Industrial photoelectric proximity sensor

The Sick VTE18-4N2812 is a cylindrical infrared sensor designed for object detection in automation environments. It operates on a 10 V DC to 30 V DC supply with an NPN switching output suitable for PLC inputs. The housing carries an IP67 enclosure rating for dust and water resistance. Operating temperatures span –25 °C to +70 °C.

Adjustable sensing with potentiometer and L/D

A built-in potentiometer lets you set the sensing range between 3 mm and 170 mm, with a maximum reach of 200 mm. The light/dark switching mode is selectable via the L/D control cable without opening the housing. Infrared LED emission with a 2.8° dispersion angle provides a focused detection beam. A 2 m PVC cable with 0.14 mm² conductors is permanently attached.

Verify voltage and wiring before ordering

Confirm your control system supplies 10 V DC to 30 V DC and accepts an NPN sinking output. Ensure the 2 m cable length and Ø 5 mm diameter suit your cable routing and connector plans. The plastic housing and PMMA optics resist typical industrial conditions but check chemical compatibility for your specific environment. No mounting hardware is included in the package.

Highlights

  • Detects objects up to 200 mm with infrared LED
  • Adjustable sensing range from 3 mm to 170 mm via potentiometer
  • Selectable light or dark switching through control cable
  • Operates reliably from –25 °C to +70 °C in IP67 housing
  • Connects directly with 2 m PVC cable at 10–30 V DC

Specifications

BrandSICK
ModelSICK VTE18-4N2812

Questions about this item

Will the potentiometer or the 2 m PVC cable need periodic replacement on the VTE18-4N2812?

The potentiometer is a sealed adjustment with no wear rating, and the 2 m PVC cable with 0.14 mm² conductors is fixed to the housing; neither has a stated replacement interval.

What limit appears first during continuous operation — the 30 mA current draw or the 70 °C temperature ceiling?

At 30 mA from a 10…30 V DC supply the sensor dissipates under 1 W, so the 70 °C ambient operating limit will be reached before the current draw becomes a constraint.

How much audible noise and heat does the VTE18-4N2812 produce when powered all day?

Solid-state infrared LED sensing with NPN switching has no moving parts, so it runs silently; heat is limited to the <1 W dissipation from the 30 mA supply current.
