Sick
Sick VTE18-3P8112 photoelectric proximity sensor PNP
Photoelectric proximity sensor with PNP output, 10 mm to 700 mm sensing range, 10–30 V DC supply and IP67 metal housing
- Detects objects up to 700 mm with infrared LED
- PNP dark-switching output signals when beam is broken
- 10–30 V DC supply suits industrial control voltages
- IP67-rated brass housing withstands dust and water jets
- 2 m PVC cable with 0.14 mm² conductors ready to install
SICK VTE18-3P8112 proximity sensor
The SICK VTE18-3P8112 is a cylindrical photoelectric proximity sensor with a PNP dark-switching output. It operates on a 10 V DC to 30 V DC supply and connects via a 2 m PVC cable. The brass nickel-plated metal housing meets IP67 enclosure rating for harsh industrial environments.
700 mm sensing range with 800 mm maximum
The sensor reliably detects objects from 10 mm to 700 mm using an infrared LED with a 2.8° dispersion angle. A potentiometer allows adjustment of the sensing distance within this window. The maximum sensing range extends to 800 mm, beyond which detection cannot be guaranteed.
PNP dark-switching output decides compatibility
The switching output is PNP with dark-switching mode, meaning the output activates when the beam is interrupted. This logic must match the controller input specification. A 2 ms response time and 30 mA power consumption complete the electrical profile for integration checks.
Highlights
- Detects objects up to 700 mm with infrared LED
- PNP dark-switching output signals when beam is broken
- 10–30 V DC supply suits industrial control voltages
- IP67-rated brass housing withstands dust and water jets
- 2 m PVC cable with 0.14 mm² conductors ready to install
Specifications
| Brand | SICK |
|---|---|
| Model | SICK VTE18-3P8112 |
