Cylindrical angled plastic sensor body with M12 connector

Sick

Sick VTE18-3N2940 Photoelectric Proximity Sensor NPN

SKU CH-XGKB-GPTA0

Detects objects up to 200 mm with an infrared LED, adjustable via potentiometer, in an IP67 cylindrical housing

  • Detects objects up to 200 mm with infrared LED
  • Adjustable sensing range from 3 mm to 170 mm via potentiometer
  • Fast 2 ms response time suits high-speed automation
  • IP67-rated plastic housing withstands dust and water ingress
  • Operates on 10–30 V DC with NPN dark-switching output

Industrial proximity sensor

The Sick VTE18-3N2940 is a cylindrical photoelectric proximity sensor designed for automated detection tasks in industrial environments. It operates on a 10 V DC to 30 V DC supply and provides an NPN dark-switching output through a male M12 4-pin connector. The IP67-rated plastic housing withstands ambient temperatures from –25 °C to +70 °C.

Sensing range and response limits

The sensor detects objects from 3 mm up to a maximum of 200 mm, with a specified sensing range of 3 mm to 170 mm using infrared LED light at a 2.8° dispersion angle. A potentiometer allows sensitivity adjustment, while the response time is 2 ms. Ripple must not exceed 10 % and power consumption is 30 mA, constraining the usable power budget.

Upgrade from basic limit switches

This unit replaces mechanical limit switches or lower-range optical sensors where non-contact detection up to 170 mm is required. The jump is worthwhile when an application demands IP67 sealing, infrared LED reliability and a fast 2 ms switching speed in a compact 75 mm cylindrical body. It is not suited for applications needing longer range, PNP output or alternative mounting formats.

Highlights

  • Detects objects up to 200 mm with infrared LED
  • Adjustable sensing range from 3 mm to 170 mm via potentiometer
  • Fast 2 ms response time suits high-speed automation
  • IP67-rated plastic housing withstands dust and water ingress
  • Operates on 10–30 V DC with NPN dark-switching output

Specifications

BrandSICK
ModelSICK VTE18-3N2940

Questions about this item

Which sensing range version suits my application best?

The sensor detects from 3 mm up to 170 mm under normal conditions, with a maximum reach of 200 mm; choose based on the distance your target will sit from the angled cylindrical head.

What does the 2 ms response time mean on the production line?

The output switches within 2 ms of detecting a change, so the sensor can reliably track objects moving at typical conveyor speeds without missing counts.

How does the M12 4-pin connector limit the installation?

The M12 4-pin male connector carries the 10–30 V DC supply and NPN dark-switching output, so cabling must match that pinout and voltage range.
