Sick
Sick VTE18-3F8840 Photoelectric Proximity Sensor PNP
Photoelectric proximity sensor detects objects from 10 mm to 800 mm using infrared LED with 2.8° dispersion, PNP light-switching output, IP67 enclosure, and M12 connector for 10–30 V DC supply
- Reliable detection up to 700 mm with infrared LED
- Precise 2.8° beam angle for focused sensing
- PNP light-switching output integrates with 10–30 V DC systems
- Rugged IP67 housing withstands –25 °C to +70 °C
- Quick M12 4-pin connector speeds installation
Industrial detection sensor
The Sick VTE18-3F8840 is a cylindrical photoelectric proximity sensor with an angled light emission design. It operates on a 10 V DC to 30 V DC supply with PNP switching output and light switching mode. An M12 4-pin male connector provides the electrical interface. The IP67 enclosure rating suits harsh industrial environments.
Replaces basic limit switches
This sensor upgrades from mechanical contact switches where non-contact detection reduces wear and maintenance. The infrared LED source with a 2.8° dispersion angle offers precise targeting. The potentiometer allows sensing range adjustment without software tools. The 2 ms response time supports high-speed automation lines.
Handles 10 mm to 700 mm range
Reliable object detection covers 10 mm to 700 mm with a maximum reach of 800 mm. The plastic housing and PMMA optics withstand ambient temperatures from –25 °C to +70 °C. Power consumption stays at 30 mA with 10 % ripple tolerance. UL file NMFT2.E175606 confirms compliance for North American installations.
Highlights
- Reliable detection up to 700 mm with infrared LED
- Precise 2.8° beam angle for focused sensing
- PNP light-switching output integrates with 10–30 V DC systems
- Rugged IP67 housing withstands –25 °C to +70 °C
- Quick M12 4-pin connector speeds installation
Specifications
| Brand | SICK |
|---|---|
| Model | SICK VTE18-3F8840 |
Questions about this item
What size is the M12 connector on this sensor?
The sensor uses a male M12 4-pin connector for power and signal connections.
How do I set the sensing distance on the VTE18-3F8840?
Turn the built-in potentiometer to adjust the detection range between 10 mm and 700 mm.
How often should I clean the optics on this sensor?
Wipe the PMMA lens periodically to maintain the 2.8° infrared beam, especially in dusty environments.
