Sick VS/VE18-4P3912 Through-beam photoelectric sensor PNP
A through-beam photoelectric sensor with 0 to 20 m range, PNP output and IP67 enclosure
- Detect objects up to 20 m with through-beam infrared sensing
- Adjust sensitivity precisely using 270° potentiometer control
- Reliable PNP switching at 250 Hz response frequency
- Rugged IP67 housing withstands –25 °C to +70 °C environments
- Compact M18 cylindrical design fits tight installation spaces
Industrial detection sensor
The Sick VS/VE18-4P3912 is a cylindrical through-beam photoelectric sensor designed for automation and safety applications. It operates on 10 V DC to 30 V DC supply voltage and provides a PNP switching output with selectable light or dark switching mode. The IP67-rated plastic housing suits harsh industrial environments.
20 metre maximum sensing range
Infrared LED emission achieves a maximum sensing range of 0 m to 20 m with a practical range up to 14 m. The radial optical axis produces a 700 mm light spot at 14 m distance with an approximate 2.8° dispersion angle. Sensitivity is adjustable via a 270° potentiometer for precise detection tuning.
2 metre PVC cable included
A 4-wire PVC cable of 2 m length with 0.14 mm² conductor cross-section and 5 mm diameter is permanently attached for direct wiring. The sensor weighs 200 g and features circuit protection classes A, B, C and D. UL file NMFT2.E175606 confirms compliance for North American installations.
Highlights
- Detect objects up to 20 m with through-beam infrared sensing
- Adjust sensitivity precisely using 270° potentiometer control
- Reliable PNP switching at 250 Hz response frequency
- Rugged IP67 housing withstands –25 °C to +70 °C environments
- Compact M18 cylindrical design fits tight installation spaces
Specifications
| Brand | SICK |
|---|---|
| Model | SICK VS/VE18-4P3912 |
Questions about this item
How far will the sensor reliably detect an object in a real installation?
The rated sensing range is 0 m to 14 m, with a maximum possible range of 20 m under ideal conditions.
What supply voltage range does the sensor accept and what output type does it provide?
It operates on 10 V DC to 30 V DC and provides a PNP switching output with a maximum load current of 100 mA.
What thread size and cable length are needed to mount and wire this sensor?
The housing uses an M18 x 1 thread for mounting and comes with a 2 m, 4-wire PVC cable of 0.14 mm² cross-section.
