Sick IME12-02BPSZWDSS02 Inductive Proximity Sensor PNP 2 mm 8 m Cable
Flush-mount M12 inductive sensor detects metal at 2 mm with PNP normally-open output on an 8 m PVC cable
- Reliable detection at 2 mm sensing range
- Fast response with 2,000 Hz switching frequency
- Durable IP67-rated metal housing withstands harsh environments
- Flexible 8 m PVC cable simplifies installation
- Wide 10–30 V DC supply voltage suits industrial systems
Industrial proximity sensor
The Sick IME12-02BPSZWDSS02 is a cylindrical inductive sensor with a 2 mm sensing range and PNP normally-open output. It operates on 10 V DC to 30 V DC and delivers a 2,000 Hz switching frequency for automated position detection. The nickel-plated brass housing meets IP67 and withstands –25 °C to +75 °C. It suits machine builders and maintenance engineers who need reliable metal detection in harsh environments.
Flush mount with 8 m cable
The M12 × 1 thread allows flush installation in metal structures with a maximum tightening torque of 12 Nm. A 3-wire PVC cable of 8 m length and 3.9 mm diameter removes the need for a separate connector and simplifies routing to the control cabinet. The 0.25 mm² conductors connect directly to PLC inputs or relay modules. Buyers who require a plug-in connector or a longer cable run will need a different model.
Low power with full protection
Current consumption is 10 mA with a 2 V voltage drop at 200 mA continuous load. Built-in short-circuit, reverse-polarity and power-up pulse protection guard the output against wiring faults. The sensor survives 30 g mechanical shock and 10 Hz to 55 Hz vibration at 1 mm amplitude. EMC compliance follows EN 60947-5-2 and UL file NRKH.E181493. Thermal drift stays within ±10 % of the sensing range across the temperature span.
Highlights
- Reliable detection at 2 mm sensing range
- Fast response with 2,000 Hz switching frequency
- Durable IP67-rated metal housing withstands harsh environments
- Flexible 8 m PVC cable simplifies installation
- Wide 10–30 V DC supply voltage suits industrial systems
Specifications
| Brand | Sick |
|---|---|
| Model | SICK IME12-02BPSZWDSS02 |
Questions about this item
At 2,000 Hz switching frequency, does the 2 V voltage drop limit how long the sensor can run continuously?
The sensor is rated for continuous operation with a 2 V drop at up to 200 mA load across the 10 V to 30 V DC supply range, so the voltage drop itself does not impose a time limit.
With an 8 m PVC cable and IP67 rating, how much heat or noise does the unit produce during all-day operation?
The device has no moving parts and a maximum current consumption of 10 mA, so it generates negligible heat and no audible noise during continuous use.
What voltage source and cabling must already be in place to connect this 3-wire PNP sensor?
A 10 V to 30 V DC supply and a compatible 3-wire DC circuit are required; the sensor comes with an 8 m PVC cable (0.25 mm² conductors, Ø 3.9 mm) for direct wiring.
