Small rectangular red plastic sensor with 2m cable

Sick

Sick GL6-N1112 NPN photoelectric sensor 10-30V 2m cable

SKU CH-G91K-WVE87 MPN GL6-N1112

Miniature NPN photoelectric retro-reflective sensor with 5 m range, visible red PinPoint LED, 2 m PVC cable and IP67 enclosure

  • TypeTest Equipment
  • Color/FinishRed
  • Item Count1 pack
  • Selling UnitBox
  • Parts3 Years
  • Labor1 Year
  • Detects objects up to 6 metres using retro-reflective photoelectric principle
  • Operates on 10 to 30 V DC supply with 30 mA power consumption
  • Switches at 1 000 Hz with response time under 625 µs for fast detection
  • IP67 rated ABS/PC housing withstands –25 °C to +55 °C operating temperatures
  • Includes stainless steel mounting bracket and P250 reflector for immediate installation

Miniature photoelectric sensor for industrial

The Sick GL6-N1112 is a retro-reflective photoelectric sensor with dual lens optics and a visible red PinPoint LED. It operates on a 10-30 V DC supply and provides an NPN switching output with selectable light or dark switching mode. The sensor is housed in a rectangular ABS/PC plastic enclosure rated IP67 and weighs 60 g. A 2 m PVC cable and a stainless steel mounting bracket with reflector are supplied.

Suits automation needing a compact 6 m range sensor

This unit fits applications that require a small rectangular sensor with a maximum sensing range of 6 m and a 1 kHz switching frequency. The fixed 2 m cable and lack of sensitivity adjustment limit its use where connectorised wiring or fine range tuning are needed. Buyers who need a different output type, longer cable or adjustable sensing distance should look at other models.

Simple bracket mounting with fixed cable wiring

Installation uses the included stainless steel bracket for quick mechanical fixing and the pre-wired 3-wire cable for electrical connection. The cable uses 0.14 mm² conductors and requires a 10-30 V DC supply within the ±10 % ripple specification. Common issues include exceeding the 100 mA output current limit or wiring the NPN output incorrectly for the chosen light/dark mode.

Highlights

  • Detects objects up to 6 metres using retro-reflective photoelectric principle
  • Operates on 10 to 30 V DC supply with 30 mA power consumption
  • Switches at 1 000 Hz with response time under 625 µs for fast detection
  • IP67 rated ABS/PC housing withstands –25 °C to +55 °C operating temperatures
  • Includes stainless steel mounting bracket and P250 reflector for immediate installation

Specifications

BrandZIBOO
ModelGL6-N1112
TypeTest Equipment
Color/FinishRed
Item Count1 pack
Selling UnitBox
Parts3 Years
Labor1 Year

Questions about this item

What power supply must I already have to run the GL6-N1112?

The sensor needs a 10 V DC to 30 V DC supply with no more than ± 10 % ripple and draws up to 30 mA.

Will the GL6-N1112 work with my existing NPN-input PLC module?

Yes, it provides an NPN switching output rated at 100 mA maximum with light/dark switching selectable via the built-in selector.

How can I verify the GL6-N1112 is detecting correctly after wiring it?

The visible red PinPoint LED produces an 8 mm spot at 350 mm; align it to the supplied P250 reflector and watch the output toggle within 625 µs at up to 1 000 Hz.
