Red flush illuminated push button, 22 mm plastic bezel

Schneider Electric

Schneider Electric ZB5AW543 22 mm illuminated push button, red

SKU CH-VBAM-4QJVV

A 22 mm flush push button with red illumination, momentary action and IP66 protection for industrial control panels

  • TypeIndustrial Electrical Controls & Automation
  • Size22 mm
  • Red illuminated operator for clear status indication
  • 22 mm flush booted design fits standard panels
  • IP66 and NEMA 4X ratings resist dust and water jets
  • Complies with IEC 60947, UL 508, CSA 22.2 and RoHS standards
  • Plastic head and bezel suit industrial control applications

Schneider Electric 22 mm Illuminated Push Button

The Schneider Electric ZB5AW543 is a 22 mm red illuminated push button designed for industrial control panels and automation systems. It suits panel builders and maintenance engineers who need a momentary flush booted operator for machine start, stop or reset functions.

IP66 and NEMA 13 4X Environmental Limits

The operator carries an IP66 rating and NEMA 13 and 4X enclosure ratings, meaning it resists powerful water jets, oil and non-corrosive coolants in indoor or outdoor installations. It is not rated for prolonged submersion or for hazardous locations requiring higher NEMA classifications such as 4X with corrosion protection beyond the stated standard.

Momentary Flush Booted Action Decides Fit

The single specification that determines suitability is the momentary flush booted operation: the contact closes only while the button is held and opens immediately on release. Buyers who need a maintained or latch action, or who require an extended head for glove use, must select a different operator type.

Highlights

  • Red illuminated operator for clear status indication
  • 22 mm flush booted design fits standard panels
  • IP66 and NEMA 4X ratings resist dust and water jets
  • Complies with IEC 60947, UL 508, CSA 22.2 and RoHS standards
  • Plastic head and bezel suit industrial control applications

Specifications

BrandSCHNEIDER ELECTRIC
TypeIndustrial Electrical Controls & Automation
Size22 mm

Questions about this item

Which illuminated push button version should I choose for a 22 mm panel cut-out?

The ZB5AW543 is a 22 mm flush booted operator with a red plastic head and bezel, designed for a standard 22 mm mounting hole in industrial control panels.

What does the IP66 rating mean when the button is installed in a machine?

IP66 certifies the operator as dust-tight and protected against powerful water jets, so the switch internals stay clean and dry in wash-down or outdoor environments.

What standards apply to the NEMA 13 and 4X ratings on this operator?

NEMA 13 and 4X confirm protection against oil, coolant, spraying water and corrosion, matching the IEC 60529 IP66 test and the UL 508 industrial control listing.
