Schneider Electric illuminated white selector switch, short handle, chrome bezel, 22 mm

Schneider Electric

Schneider Electric ZB4BK1813 Short Handle Selector Switch Illuminated White 3 Position 22 mm

SKU CH-S5PN-BM45G

A 22 mm illuminated selector switch with three maintained and momentary positions, rated IP66, IP67, IP69 and IP69K for harsh environments

  • Engine BrandSCHNEIDER ELECTRIC
  • Engine Size22 mm
  • White illuminated lever for clear status indication
  • 22 mm mounting diameter fits standard industrial panels
  • Three maintained and momentary positions for versatile control sequences
  • IP66, IP67, IP69 and IP69K ratings withstand high-pressure wash-down and dust ingress
  • NEMA 1, 2, 3, 4, 13 enclosure ratings suit indoor and outdoor industrial environments

22 mm Illuminated Selector Switch

The Schneider Electric ZB4BK1813 is a short-handle illuminated selector switch with a 22 mm mounting diameter and three maintained or momentary positions. It suits control panels that require a white lever operator and chrome-plated metal bezel in industrial environments.

NEMA and IP Ratings Limit Exposure

The switch carries NEMA ratings 1, 2, 3, 4, 13 and IP ratings IP66, IP67, IP69, IP69K, meaning it resists dust, water jets, temporary immersion and high-pressure wash-down. It is not rated for hazardous-location or explosion-proof applications.

Three-Position Cam Action Decides Fit

The operator provides a maintained/maintained/momentary cam sequence with no cam included, so the contact block arrangement must match that exact switching logic. Panels needing a different position count or cam profile cannot use this unit.

Highlights

  • White illuminated lever for clear status indication
  • 22 mm mounting diameter fits standard industrial panels
  • Three maintained and momentary positions for versatile control sequences
  • IP66, IP67, IP69 and IP69K ratings withstand high-pressure wash-down and dust ingress
  • NEMA 1, 2, 3, 4, 13 enclosure ratings suit indoor and outdoor industrial environments

Specifications

Engine BrandSCHNEIDER ELECTRIC
Engine Size22 mm

Questions about this item

Should I choose the 3-position maintained/maintained/momentary switch or a different action type?

This model uses a maintained/maintained/momentary action with a short white lever; select it when you need the centre position held and the right position spring-return.

What does the IP66/IP67/IP69/IP69K rating mean once the switch is installed in a panel?

The switch withstands powerful water jets, temporary immersion, and high-pressure high-temperature wash-down when correctly mounted in a 22 mm cut-out.

Which standards does the 22 mm selector switch meet for industrial control panels?

It complies with CSA C22.2 No. 14, EN/IEC 60947-1, -5-1, -5-4, -5-5, JIS C8201-1, -5-1 and UL 508.
