Schneider Electric 22 mm illuminated push button yellow metal head chrome bezel

Schneider Electric

Schneider Electric XB4BW35G5 22 mm illuminated push button yellow

SKU CH-99FR-4NSHX

A 22 mm illuminated push button with momentary action, 1NO/1NC contacts rated at 10 A and 600 V AC, and IP66, IP67, IP69, IP69K sealing

  • TypeIndustrial Electrical Controls & Automation
  • Size22mm
  • Bright status indication with yellow illuminated head
  • Reliable switching via 1NO/1NC contact configuration
  • Durable chrome-plated metal bezel resists wear
  • Suited to harsh environments with IP66 IP67 IP69 IP69K ratings
  • Standard 22 mm cut-out fits common panels

Illuminated 22 mm push button

Schneider Electric XB4BW35G5 is a 22 mm yellow illuminated push button designed for industrial control panels and automation systems. It suits engineers and maintenance teams who need a visible, momentary actuator for machine start or stop functions.

Contact rating and environmental limits

The switch carries a 10 A rating at 600 V AC with NEMA A600/Q600 designation. Its enclosure meets NEMA 1, 2, 3, 4, 4X, 12, 13 and IP66, IP67, IP69, IP69K, so it withstands wash-down, dust and temporary immersion but is not rated for continuous submersion or hazardous locations.

Single operator headroom

One guarded metal operator with 1NO/1NC contacts handles typical start-stop or jog circuits within the 10 A limit. It runs out of capacity for multi-function stations or higher current loads that would require additional contact blocks or a larger enclosure.

Highlights

  • Bright status indication with yellow illuminated head
  • Reliable switching via 1NO/1NC contact configuration
  • Durable chrome-plated metal bezel resists wear
  • Suited to harsh environments with IP66 IP67 IP69 IP69K ratings
  • Standard 22 mm cut-out fits common panels

Specifications

BrandSCHNEIDER ELECTRIC
TypeIndustrial Electrical Controls & Automation
Size22mm

Questions about this item

Which contact form should I choose for a simple start-stop circuit?

The 1NO/1NC contact form gives one normally-open and one normally-closed circuit, ideal for standard start-stop wiring.

What does the 10 A 600 V AC rating mean when the button is installed?

It means the contacts can safely switch up to 10 amps at 600 volts AC in the control circuit.

How do the NEMA and IP ratings limit where I can mount this button?

NEMA 1, 2, 3, 4, 4X, 12, 13 and IP66, IP67, IP69, IP69K allow indoor and outdoor use with high-pressure washdown.
