Yellow illuminated push button 22 mm chrome bezel metal head

Schneider Electric

Schneider Electric XB4BW35B5 Illuminated Push Button Yellow 22 mm

SKU CH-J3XZ-5HVYT

A 22 mm yellow illuminated push button with momentary action, 1NO/1NC contacts rated 10A at 600V AC, and IP66, IP67, IP69, IP69K sealing

  • TypeIndustrial Electrical Controls & Automation
  • Size22 mm
  • Momentary action for precise control
  • Illuminated yellow head for clear status visibility
  • 10 A at 600 V AC contact rating
  • IP66 IP67 IP69 IP69K and NEMA 1 2 3 4 4X 12 13 sealing
  • 22 mm metal bezel fits standard panel cut-out

22 mm Yellow Illuminated Push Button

This Schneider Electric XB4BW35B5 is a 22 mm panel-mounted illuminated push button designed for industrial control panels. It suits machine builders and maintenance teams who need a visible, momentary actuator for start, stop or emergency functions. The yellow lens provides clear status indication in brightly lit environments. Its 1NO/1NC contact block supports both signalling and safety circuits.

Metal bezel, chrome-plated guard

The operator head uses a metal body with a chrome-plated metal bezel and a round guarded button that resists accidental actuation. Contacts are rated at 10A at 600V AC with NEMA A600/Q600 designation. NEMA 1, 2, 3, 4, 4X, 12, 13 ratings plus IP66, IP67, IP69 and IP69K mean the device withstands wash-down, oil, dust and high-pressure water jets. The full-voltage illumination module simplifies wiring without external transformers.

Momentary action and single-operator layout limit

The momentary action returns automatically when released, so it cannot hold a circuit latched without external logic. Only one operator is present, preventing multi-function or selector-style operation from this single cut-out. The fixed yellow colour and non-legendable cap restrict custom labelling for multi-language panels. Buyers needing maintained positions, key operation or coloured legend plates must choose a different operator type.

Highlights

  • Momentary action for precise control
  • Illuminated yellow head for clear status visibility
  • 10 A at 600 V AC contact rating
  • IP66 IP67 IP69 IP69K and NEMA 1 2 3 4 4X 12 13 sealing
  • 22 mm metal bezel fits standard panel cut-out

Specifications

BrandSCHNEIDER ELECTRIC
TypeIndustrial Electrical Controls & Automation
Size22 mm

Questions about this item

What contact rating does the 22 mm illuminated push button provide at 600 V AC?

The button is rated for 10 A at 600 V AC with NEMA designations A600 and Q600.

What panel cut-out size and bezel material are required for mounting?

It fits a 22 mm cut-out and uses a chrome-plated metal bezel.

How is the button wired and which terminal step is often missed?

Connect the 1NO and 1NC contacts to the screw terminals; the step often missed is tightening both contact blocks securely.
