Schneider Electric RXM2AB2BD 24 V DC DPDT 12 A 8-pin relay

SKU CH-GWB9-9VXRH

A plug-in relay with an 8-pin DPDT contact rated 12 A at 24 V DC coil voltage and LED status indicator

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • DPDT contact form enables versatile switching circuits
  • 12 A rating at 250 V AC and 28 V DC handles substantial loads
  • 24 V DC coil voltage suits common control systems
  • Lockable push-to-test button simplifies maintenance checks
  • LED indicator and mechanical flag provide clear status feedback

Plug-in relay for 24 V DC control circuits

The Schneider Electric RXM2AB2BD is an enclosed, square-base relay designed for general-purpose industrial automation. It mounts by plugging into a compatible socket and provides double-pole double-throw switching for loads up to 12 A at 250 V AC or 28 V DC. A built-in LED indicator and mechanical flag give immediate visual confirmation of coil status, while the lockable push-to-test button allows manual actuation during commissioning without removing the cover.

Sustained-load behaviour

Under continuous operation the relay carries its full 12 A rating through flat quick-connect pins rated 0.09 in wide, minimising contact resistance and heat rise. The enclosed body depth of 1.57 in and height of 1.06 in allow dense panel mounting while maintaining insulation distances for 250 V AC circuits. Coil power at 24 V DC remains stable over long duty cycles, and the sealed construction protects contacts from dust and humidity that can degrade performance in unsealed alternatives.

Replaces non-indicating or solder-terminal relays

This unit upgrades installations that use older relays lacking status LEDs, mechanical flags or lockable test functions, reducing troubleshooting time on live panels. It also supersedes relays with solder or screw terminals where quick-connect wiring is preferred for faster module swap-outs. The jump is worthwhile when maintenance crews need visible coil confirmation and tool-free testing without rewiring the socket or changing the panel cut-out.

Highlights

  • DPDT contact form enables versatile switching circuits
  • 12 A rating at 250 V AC and 28 V DC handles substantial loads
  • 24 V DC coil voltage suits common control systems
  • Lockable push-to-test button simplifies maintenance checks
  • LED indicator and mechanical flag provide clear status feedback

Specifications

BrandSCHNEIDER ELECTRIC
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

How much heat does the 12 A DPDT relay generate when energised continuously at 24 V DC?

The coil draws only 24 V DC and the contacts are rated 12 A at 250 V AC or 28 V DC, so steady-state heat remains low inside the enclosed 1.57 in deep body.

Which 8-pin socket with 0.09 in flat-pin spacing is required to mount this square-base relay?

A standard octal plug-in socket matching the 8 flat pins on 0.09 in centres accepts the relay; the lockable push-to-test button and LED indicator remain accessible through the socket window.

Can the 12 A contacts switch the 240 V AC coils of older contactors in the same panel?

Yes — the DPDT contacts are rated 12 A at 250 V AC, covering 240 V AC control circuits, while the 24 V DC coil isolates cleanly from legacy AC wiring.
