Grey insulated wire ferrules, 500 pack, 18 AWG

Panduit

Panduit FTD76-10-D Ferrule 18 AWG PK500

SKU CH-HDQ0-ME7HP

Pack of 500 gray-insulated 18 AWG ferrules with 9/16 in. insertion length, tin-plated copper barrels and polypropylene insulation rated to 221 °F

  • Tin-plated copper barrel resists corrosion
  • Gray polypropylene insulation rated to 221 °F
  • 9/16 in insertion length suits standard terminals
  • Pack of 500 ferrules for high-volume wiring jobs
  • UL 486F listed and CSA C22.2 No. 291-14 certified

Wire Ferrule 18 AWG 500 Pack

These tin-plated copper ferrules suit 18 AWG conductors and meet CSA C 22.2 No. 291-14, DIN 46228 and UL 486F listings. The polypropylene insulation is grey and rated to 221 Degrees F. Each ferrule has a 9/16 in insertion length and a 0.28 in barrel length. The pack contains 500 pieces for high-volume wiring tasks.

Check Wire Gauge and Crimp Tool

Verify that every conductor is exactly 18 AWG because the ferrule accepts no smaller or larger size. Confirm the crimp tool matches the 0.08 in ferrule diameter and 0.09 in barrel diameter. Ensure the application temperature stays within the 221 Degrees F limit. The terminal block or connector must accept a 9/16 in insertion depth.

Copper Barrel Tin Finish Polypropylene Sleeve

The copper barrel with tin plating resists oxidation during repeated thermal cycles. The polypropylene sleeve provides dielectric protection and the grey colour aids visual identification in dense looms. The crimp termination creates a gas-tight joint without solder. The 500-piece quantity supports production runs and panel builds without frequent re-ordering.

Highlights

  • Tin-plated copper barrel resists corrosion
  • Gray polypropylene insulation rated to 221 °F
  • 9/16 in insertion length suits standard terminals
  • Pack of 500 ferrules for high-volume wiring jobs
  • UL 486F listed and CSA C22.2 No. 291-14 certified

Specifications

BrandPANDUIT

Questions about this item

What comes in the pack and is a crimp tool included?

The pack contains five hundred gray polypropylene insulated ferrules sized for 18 AWG wire; a crimp tool is not included and must be purchased separately.

Which ferrule size should I choose for my 18 AWG wire?

This model is built for 18 AWG only, with a 0.08 in ferrule diameter, 0.09 in barrel diameter and 0.28 in barrel length — select it when your wire matches that gauge.

What does the 9/16 in insertion length mean when I crimp the ferrule?

It means 9/16 in of the ferrule barrel sits inside the terminal block after crimping, giving a secure copper-to-copper contact rated to 221 °F and listed to UL 486F and CSA 22.2 No. 291-14.
