Flat silver polyester web sling with reinforced eyes lying coiled on a surface

Lift-all

Lift-all EE2803TTX10 Web Sling Type 4 10 ft 3 in Polyester Silver

SKU CH-5K3S-A8BP1

A 10 ft polyester web sling rated for 8,800 lb vertical, 7,040 lb choker and 17,600 lb basket hitches, built to ASME B 30.9 and OSHA 1910.184 standards

  • Type 4 design suits multiple hitch configurations
  • 10 ft length with 11 in eyes for versatile rigging
  • Two-ply polyester construction rated for 8,800 lb vertical capacity
  • Choker capacity 7,040 lb and basket capacity 17,600 lb for heavy loads
  • Meets ASME B30.9 and OSHA 1910.184 standards

Lift-all EE2803TTX10 Web Sling Type 4

This Lift-all EE2803TTX10 is a Type 4 web sling built for lifting and rigging tasks. It uses polyester webbing with two plies and measures ten feet long with a three-inch overall width. Silver and blue colouring aids visual inspection on site. The sling meets ASME B30.9, OSHA 1910.184 and WSTDA standards.

Suited for vertical, choker and basket hitches

Rated capacities are 8,800 pounds vertical, 7,040 pounds choker and 17,600 pounds basket. The eleven-inch eyes allow straightforward hook or shackle connection. Buyers needing a different length, width or ply count should look at other configurations. Applications requiring hardware attachments or multi-leg assemblies are not covered by this model.

Type 4 construction with 17,600 lb basket capacity

The single specification that decides fit is the Type 4 flat-eye design combined with a 17,600-pound basket hitch rating. This defines the sling's load-handling envelope for basket configurations. Verify the hitch method and capacity requirement against this figure before purchase.

Highlights

  • Type 4 design suits multiple hitch configurations
  • 10 ft length with 11 in eyes for versatile rigging
  • Two-ply polyester construction rated for 8,800 lb vertical capacity
  • Choker capacity 7,040 lb and basket capacity 17,600 lb for heavy loads
  • Meets ASME B30.9 and OSHA 1910.184 standards

Specifications

BrandLIFT-ALL

Questions about this item

What is the eye length of the EE2803TTX10 web sling?

The eye length is 11 in, which determines the minimum hardware diameter that can pass through the sling eyes for a secure connection.

How should the Type 4 web sling be rigged to avoid twisting during a lift?

Lay the sling flat so both eyes align in the same plane, then attach to the load and hook without allowing the body to rotate under tension.

When must this polyester web sling be removed from service?

Remove it if you see cuts, abrasion, heat damage, melting, broken stitches, or if the identification tag is missing or illegible.
