Stainless steel 16mm latching push button with blue LED ring

JacobsParts Inc.

JacobsParts Inc. LTCH-C3-BLU 16mm 12V Latching Push Button Disconnect Stainless Steel Blue LED Waterproof IP67

SKU CH-5XTS-PQMHR MPN LTCH-C3-BLU

A 16 mm stainless-steel latching push-button switch rated 250 V 3 A with a 12 V blue LED and IP67 waterproof protection

  • TypePush Button
  • Amps3 Amps
  • Voltage250 Volts
  • MaterialMetal
  • FeaturesWaterproof
  • Latching action stays on or off with each press
  • IP67 stainless steel resists water and corrosion
  • 12 V blue LED can be wired always on or switched
  • 16 mm panel cutout with included nut and O-ring
  • Rated 250 V AC/DC at 3 A with 1NO1NC contacts

Automotive 16mm Latching Power Switch

The JacobsParts LTCH-C3-BLU is a stainless-steel push button rated for 250V AC/DC at 3A with a 12V blue LED. Its IP67 enclosure suits cars, motorcycles, boats and electronics projects where a maintained on-off action is required. The SPDT 1NO1NC circuit supports both normally open and normally closed wiring configurations.

Panel Mount With 5/8 Inch Cutout

Installation needs a 16mm hole drilled by a 5/8 inch bit; the threaded neck secures with the supplied metal nut and optional rubber O-ring for extra sealing. Total depth behind the panel is 36mm including contacts, so check clearance before cutting. The LED and switch circuits are independent, letting you choose permanent or switched illumination.

3 Amp Capacity At 250 Volts

The contacts handle 3A continuous load at up to 250V, adequate for auxiliary LED lighting, small pumps or accessory circuits. The 12V LED draws only 15mA and operates from -20°C to 55°C. It is not suited for high-current starter motors, heavy winches or mains appliances exceeding the rated amperage.

Highlights

  • Latching action stays on or off with each press
  • IP67 stainless steel resists water and corrosion
  • 12 V blue LED can be wired always on or switched
  • 16 mm panel cutout with included nut and O-ring
  • Rated 250 V AC/DC at 3 A with 1NO1NC contacts

Specifications

TypePush Button
Amps3 Amps
Voltage250 Volts
MaterialMetal
BrandJacobsParts
ModelLTCH-C3-BLU
FeaturesWaterproof

Questions about this item

How do I verify the switch is latching correctly after wiring it into my 12V circuit?

Press the button once; the blue LED should light and the connected load should power on. Press it a second time and both should turn off, confirming the maintained ON/OFF action.

Which mounting hardware and seals are supplied with the LTCH-C3-BLU?

The package includes the stainless-steel switch body, a metal securing nut and a rubber O-ring for optional extra water resistance at the panel face.

Should I choose the 12 V blue LED version or a different voltage for my auxiliary lighting project?

The built-in LED is rated for 12 V DC at 15 mA, so select this model when your system runs on a 12 V supply; other voltages would require a different switch.
