Silver aluminium filter housing with 3/4 NPT ports and automatic drain

Ingersoll/Rand

Ingersoll/Rand FA110IG 3/4" NPT 65 cfm 1 micron filter

SKU CH-SJKY-WXEZW

Particulate filter rated for 65 cfm at 250 psi with 1 micron filtration and automatic drain

  • Removes fine particles with 1 micron filtration
  • Handles 65 cfm flow for steady tool supply
  • Withstands 250 psi operating pressure safely
  • Automatic drain clears moisture without manual effort
  • Differential pressure indicator shows element condition clearly

General Purpose Particulate Filter

The Ingersoll/Rand FA110IG is a general purpose particulate filter rated for a maximum flow of 65 cfm and a maximum operating pressure of 250 psi. It suits compressed air systems that need solid particle removal down to 1 micron. The unit operates up to 176 Degrees F and uses 3/4 inch NPT inlet and outlet connections.

Aluminium Bowl with Automatic Drain

The filter body and bowl are constructed from aluminium for corrosion resistance in industrial environments. An automatic drain expels collected condensate without manual intervention, reducing maintenance downtime. Air flows left to right through the housing, which measures 3 7/8 in wide and 11 1/16 in high. A differential pressure indicator is included to signal element condition at a glance.

Series F Element and Indicator Included

The filter ships with a Series F particulate element and the differential pressure indicator already fitted, so installation is immediate. No separate drain kit is required because the automatic drain is factory installed. Buyers needing oil aerosol removal or activated carbon stages will need additional filtration modules not supplied with this unit.

Highlights

  • Removes fine particles with 1 micron filtration
  • Handles 65 cfm flow for steady tool supply
  • Withstands 250 psi operating pressure safely
  • Automatic drain clears moisture without manual effort
  • Differential pressure indicator shows element condition clearly

Specifications

BrandINGERSOLL-RAND

Questions about this item

What does the 3/4" NPT connection mean for airflow capacity?

The 3/4" NPT inlet and outlet support a maximum flow rate of 65 cfm at up to 250 psi operating pressure.

What are the exact dimensions for mounting this filter?

The housing measures 3 7/8 inches wide and 11 1/16 inches tall with an aluminum body and bowl.

How is the automatic drain installed and what is the common mistake?

The automatic drain is factory-fitted to the aluminum bowl; the frequent error is piping the 3/4" NPT ports opposite to the marked left-to-right flow arrow.
