Black rectangular network video recorder with sixteen PoE ports on the front

Hanwha Techwin

Hanwha Techwin XRN-1620SB1 16 Channel 8K NVR 24 TB 2 TB HDD

SKU CH-1D9A-MRPKA

Records up to 16 PoE camera channels at 8K resolution with 24 TB total storage and H.265/H.264/MJPEG compression

  • StandardsPOE
  • Supported ProtocolsH.265, H.264, MJPEG compression
  • Network Interface2 x RJ-45
  • Ports16
  • Video Input16 x RJ-45
  • Video Output4K video out on HDMI monitor

Hard Drive 2 Terabyte Hard Drive

  • Records 16 cameras simultaneously via 16 PoE ports
  • Stores weeks of footage on 24 TB total SATA capacity
  • Captures fine detail with up to 32MP camera support
  • Finds events fast using AI search with Wisenet AI cameras
  • Keeps recording automatically if a drive fails with ARB backup

16-Channel 8K NVR with PoE

The Hanwha Techwin XRN-1620SB1 is a network video recorder that supports up to 16 camera channels and 32MP resolution per channel. It provides 16 built-in PoE ports so each camera receives power and data through a single cable. The unit ships with a 2TB hard drive installed and accepts up to 24TB of total internal storage.

Sustained 140Mbps recording throughput

The recorder writes incoming streams at a maximum of 140Mbps and plays back at up to 32Mbps using H.265, H.264 or MJPEG compression. WiseStream dual-stream recording optimises bandwidth and storage consumption during continuous operation. Automatic Recovery Backup switches recording to a spare drive if the primary SATA disk fails, keeping the system running without interruption.

Four fixed SATA bays and dual video outputs

Four internal SATA bays hold the drives that deliver the 24TB capacity ceiling, and the ARB function uses one bay as a live spare. Video output is available through HDMI and VGA connectors for local monitoring at 4K resolution. Two RJ-45 network interfaces separate camera traffic from the management network, while the 16 PoE ports handle plug-and-play camera connection.

Highlights

  • Records 16 cameras simultaneously via 16 PoE ports
  • Stores weeks of footage on 24 TB total SATA capacity
  • Captures fine detail with up to 32MP camera support
  • Finds events fast using AI search with Wisenet AI cameras
  • Keeps recording automatically if a drive fails with ARB backup

Specifications

BrandHanwha Techwin
ModelXRN-1620SB1
Part NumberXRN-1620SB1
StandardsPOE
Supported ProtocolsH.265, H.264, MJPEG compression
Network Interface2 x RJ-45
Ports16
Video Input16 x RJ-45
Video Output4K video out on HDMI monitor

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How much power do the 16 PoE ports draw when cameras are recording all day?

The unit supports PoE and PoE+ on all 16 ports, so connected cameras receive power over the same cable that carries video; total draw depends on the cameras you attach.

Which cables and monitors must I already have to get video out of the HDMI and VGA ports?

You need an HDMI cable for 4K output or a VGA cable for the second monitor; both connectors are built into the recorder.

Will my existing H.264 cameras work with the H.265 and WiseStream encoding on this recorder?

Yes — the NVR accepts H.264, H.265 and MJPEG streams, so older cameras using H.264 continue to record without changes.
