Black rectangular network video recorder with sixteen front PoE ports and HDMI output

Hanwha Techwin

Hanwha Techwin XRN-1620SB1 16 Channel 8K NVR 24 TB

SKU CH-7AEE-YE0ZN

Records up to 16 PoE cameras at 8K resolution with 24 TB storage and H.265 compression

  • StandardsPOE
  • Supported ProtocolsH.265, H.264, MJPEG compression
  • Network Interface2 x RJ-45
  • Ports16
  • Video Input16 x RJ-45
  • Video Output4K video out on HDMI monitor

Hard Drive No Hard Drive

  • 16 PoE ports power cameras without extra cabling
  • 24 TB total storage holds weeks of footage
  • 32 MP camera support captures fine detail
  • 140 Mbps recording bandwidth ensures smooth 8K streams
  • H.265 and H.264 compression reduces storage needs

16-channel 8K NVR with 24 TB storage

The Hanwha Techwin XRN-1620SB1 is a network video recorder that supports up to 16 PoE camera channels and records at up to 32 megapixel resolution. It ships with four internal SATA hard drives providing 24 TB of total capacity. The unit is intended for installations that need a single appliance to power, record and manage multiple high-resolution cameras.

Recording bandwidth and codec limits

Maximum incoming recording bandwidth is 140 Mbps across all channels while playback tops out at 32 Mbps. Supported compression formats are H.265, H.264 and MJPEG, and dual-stream recording allows simultaneous capture at different resolutions or frame rates. WiseStream technology optimises bandwidth and storage without reducing image quality, and AI search functions become available when paired with compatible Wisenet AI cameras.

PoE connectivity and drive redundancy

Sixteen RJ-45 ports deliver both data and PoE or PoE+ power so cameras connect without separate injectors. Video output is provided through HDMI and VGA for 4K monitoring. Automatic Recovery Backup switches recording to a spare drive if a primary disk fails, keeping the system running. The recorder also supports dynamic events, enabling new camera event types without a firmware update.

Highlights

  • 16 PoE ports power cameras without extra cabling
  • 24 TB total storage holds weeks of footage
  • 32 MP camera support captures fine detail
  • 140 Mbps recording bandwidth ensures smooth 8K streams
  • H.265 and H.264 compression reduces storage needs

Specifications

BrandHanwha Techwin
ModelXRN-1620SB1
Part NumberXRN-1620SB1
StandardsPOE
Supported ProtocolsH.265, H.264, MJPEG compression
Network Interface2 x RJ-45
Ports16
Video Input16 x RJ-45
Video Output4K video out on HDMI monitor

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How many cameras can I connect to the 16 PoE ports?

You can connect up to 16 cameras directly to the built-in PoE ports, each receiving power and data over a single cable.

What does the 140 Mbps recording rate mean for daily use?

It is the total incoming bandwidth ceiling; all 16 channels combined cannot exceed 140 Mbps while recording.

What does the dual RJ-45 network interface cap in practice?

The two RJ-45 ports provide redundant or separate network paths, but total camera throughput is still limited to 140 Mbps.
